Specifications
JMQ-6A low cost brick making machine1.ISO9001/BV
2.Factory price
3.No need pallets
4.Large productivity
JMQ-6A low cost brick making machine
1. Main Technical Specifications | |
Overall Dimension | 2200×2200×2300(mm) |
Rated pressure | 6-8MPa |
Main vibration form | Mould vibration |
Cycle Time | 20 seconds |
Productivity | 8000-10000pcs/day |
Vibrating Frequency | 3500 rolls/minute |
Overall weight | 2480kg |
Motors Power | 8.2kw |
Raw Materials | crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, expanded perlite, and other industrial wastes |
Applied Products | concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc. |
2.JMQ-6A low cost brick making machine Capacity
Block type | Block size | Pcs/mould | Pcs/hour | Pcs/day
|
Hollow blocks | 400x200x200mm (16x8x8 inch) | 6 | 1000 | 7000-9000 |
Hollow blocks | 400x150x200mm (16x6x8 inch) | 8 | 1300 | 10000-13000 |
Hollow blocks | 400x250x200mm (16x10x8 inch) | 4 | 700 | 5600-7000 |
Hollow blocks | 400x120x200mm (16x5x8 inch) | 9 | 1500 | 12000-15000 |
Solid bricks | 250x175x75mm (10x7x3 inch) | 14 | 2016 | 16128-20160 |
3.Brief introduction & Photoes Show:
JMQ-6A block making machine is a mobile machine.It is large productivity than the other small block machines.This Machine is manufactured on the base of technical modifications to the original block shaping machines, one-time-vibration of molding core, hydraulic pressure, so the block density becomes higher, shaping speed quicker and block strength more even ,
This model of machine can be suitable to the customers who have any kinds of existing cement working sites.
And the consumption pallets can be reduced.
4.Packaging details:
5.Process:
We always warmly welcome you to contact us at any time!
Contact:Erica SKYPE:Ericaliu121 Mail:sales01 at Phone:0086-18315754985
