Specifications
block machine mixer JS500 concrete mixer1,ISO9001/BV certifications
2.little noice good working performance
block machine mixer JS500 concrete mixer
Specification of JS500 mixer
Output capacity | 500L | ||
Input capacity | 800L | ||
Capacity | ≥25m3/h | ||
Max aggregate size | 80/60mm | ||
Agitating vane | RPM | 35r/min | |
Quantity | 2*7 | ||
Mixer motor | Model | Y180m-4 | |
Power | 18.5kw | ||
Windless motor | Model | YEZ1325-4-B5 | |
Power | 5.5kw | ||
Water pump motor | Model | 50DWB20-8A | |
Power | 7.5kw | ||
Hopping lifting speed | 18m/min | ||
Over size | Transporting position | 3050*2300*2680mm | |
Working position | 4461*3050*5225mm | ||
Weight | 4000kg | ||
Unloading height | 1500mm | ||
JS500 concrete mixer is dual horizontal shaft concrete mixer, which can work independently,
also can be composed the concrete mixing plant with other matched equipment., and it can
be applicable to large, medium and small precast concrete products factory and roads,
railways, bridges, water conservancy, civil construction project, and it can mix dry and hard
concrete, plastic concrete, light aggregate concrete and all kind of mortar, it is one kind of
high efficiency, widely used construction machinery. It owns reasonable design ,and its
mechanical accessories used industry standard parts, and its maintenance is much convenient.
Contact person:
Contact Name: harold song
Skype:harold1988610
Mobile: 86 18264925825
M: harold2010610 at
