High Effciency Stone Grinding Machine,Wet Ball Mill

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 25 Set / Sets per Month
Port Tianjing/Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Zhongke
Model Number	2700*4500	Certification	ISO9001
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas
Weight	102t

Product Description

Ball mill

Ball mill is the key equipment for grinding after the crushing process, which is widely used in the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics

It can be used for the dry and wet grinding for all kinds of ores and other grind-able materials.

Working Principle:

The ball mill is a horizontal rotating device transmitted by the outer gear.

The materials are transferred to the grinding chamber through the quill shaft uniformly.

There are ladder liner and ripple liner and different specifications of steel balls in the chamber.

The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials.

The ground materials are discharged through the discharging board thus the grinding process is finished.

Parameters

Model	input size(mm)	Output size(mm)	Weight of ball(t)	Speed of bucket(r/min)	Power(kw)	Capacity(t/h)	Weight(kg)
900*1800	15	0.075-0.89	1.9	37	15	0.5-2	3400
900*2100	15	0.075-0.4	2.3	37	18.5	0.4-2	3900
900*3000	25	0.075-0.4	3.85	35	30	1.1-2.5	7780
1200*2400	25	0.075-0.4	4.6	35	30	1.3-3.2	8650
1200*2800	25	0.075-0.4	5.4	35	37	1.5-3.7	10020
1200*4500	25	0.075-0.4	8.6	35	45	2.7-6.79	14000
1500*3000	25	0.047-0.4	9	29	75	3.3-8.2	14122
1500*3500	25	0.047-0.4	10.5	29	75	3.3-8.5	15636
1500*4500	25	0.047-0.4	13.5	29	90	4.5-12	20000
1500*5700	25	0.047-0.4	17	29	110	2.6-14	25000
1830*3000	25	0.047-0.4	13.5	24	135	4-15	28000
1830*4500	25	0.047-0.4	20	24	155	4-19	32000
1830*7000	25	0.047-0.4	31.5	24	210	6-22	37500
2100*3000	25	0.047-0.4	18	22	210	6.4-28	40790
2100*4000	25	0.047-0.4	21.5	22	210	7.6-28	43454
