Frequency inverter 3000w off grid pure sine wave inverter, 12V/24V48VDC to 100/110/120/220/230/240V AC.

Specifications

frequency inverter
1.Input:12V/24V48V DC
2.Output:100/110/120/220/230/240V AC
3.Pure sine wave

Frequency inverter 3000w off grid pure sine wave inverter, 12V/24V48VDC to 100/110/120/220/230/240V AC.



Sample Purchase online: Click here











Technical Data

Model			RX-3000-S
AC output voltage			100/110/120/V or 200/220/230/240V
Output power			3000W
Instant peak power			6000W
output wave form			pure sine wave
output frequency			50HZ or 60HZ(±2%)
Output	THD		<4%
Input	DC input voltage		12V or 24V or 36V or 48V
	voltage range		10.5-15V or 21-30V or 33-45V or 42--60V
	no-load current		<0.8A
	Efficiency		>88%
	Fuse	12V	40A*9
		24V	20A*9
		48V	20A*9
Protection	Low voltage alarm		10±0.5V or 20±1V or 30±1V or 38±2V
	Low voltage shut down		9.5±0.5V or 19±1V or 28±1V or 37±2V
	Over voltage shut down		15.5V or 31V or 46V or 64V
	Over temperature shut down		Yes
	short-circuit protection		Yes
	Over load protection		120%
	Inversed protection		Fuse Inversed
Enviroment	Work temperature		—20°c to +50°c
	Humidity		20%~90%RH non-dondensation
	Storage tmeperature		—30°c to+70°c
Others	Size(mm)		410*200*150
	N.W.(KG)		7.5±0.5KG
	G.W.(KG)		8.5KG













Description



1. This power inverter instantly convert low voltage DC power to high voltage AC household power.



2. High reliability and low failure rate by using the advanced Double-CPU single chip intellectual



control technology.



3. Pure sine wave output. Small, light and artistic, benefited from adopting the SMD pastern



 technology.



4. Cooling fan is intellectual controlled, and its working status is controlled by CPU, which



mostly increased its service life and helps to save the power consumption, improve work



efficiency and lower the working noise.



5. You can use many places. Such as Solar electric energy generation, Wind power generation,



Communication equipment, Industrial intellectual control system, Small sized emergency power



supply system


























Socket design for different countries
