1500W off grid power inverter with charger. 12/24/48V DC to 100/110/120/220/230/240V AC

Specifications

power inverter with charger
1.Input:12V/24V48V/110VDC
2.Output:100/110/120/220/230/240V AC
3.Pure sine wave

1500W off grid power inverter with charger. 12/24/48V DC to 100/110/120/220/230/240V AC



Sample Purchase online: Click here











Technical Data



Model			RX-1500-S
AC output voltage			100/110/120/V or 200/220/230/240V
Output power			1500W
Instant peak power			3000W
output wave form			pure sine wave
output frequency			50HZ or 60HZ(±2%)
Output	THD		<4%
Input	DC input voltage		12V or 24V or 36V or 48V
	voltage range		10.5-15V or 21-30V or 33-45V or 42--60V
	no-load current		<0.75A
	Efficiency		>88%
	Fuse	12V	50A*4
		24V	30A*4
		48V	30A*4
Protection	Low voltage alarm		10±0.5V or 20±1V or 30±1V or 38±2V
	Low voltage shut down		9.5±0.5V or 19±1V or 28±1V or 37±2V
	Over voltage shut down		15.5V or 31V or 46V or 64V
	Over temperature shut down		Yes
	short-circuit protection		Yes
	Over load protection		120%
	Inversed protection		Fuse Inversed
Environ ment	Work temperature		-20°C to +50°C
	Humidity		20%~90%RH non-dondensation
	Storage temperature		-30°C to+70°C
Others	Size(mm)		380*180*100
	N.W.(KG)		4.0±0.5KG
	G.W.(KG)		5KG















Description



1. This power inverter instantly convert low voltage DC power to high voltage AC household power.



2. High reliability and low failure rate by using the advanced Double-CPU single chip intellectual



control technology.



3. Pure sine wave output. Small, light and artistic, benefited from adopting the SMD pastern



 technology.



4. Cooling fan is intellectual controlled, and its working status is controlled by CPU, which



mostly increased its service life and helps to save the power consumption, improve work



efficiency and lower the working noise.



5. You can use many places. Such as Solar electric energy generation, Wind power generation,



Communication equipment, Industrial intellectual control system, Small sized emergency power



supply system






































Socket design for different countries
