Magnetite Iron Ore Beneficiation Plant

 Magnetite iron ore beneficiation plant

Part 1.  General process:

♦ Primary crushing (Jaw crusher)

♦ Secondary crushing (Fine jaw crusher)

♦ Screening (Vibrating screen)

♦ Third crushing (Fine jaw crusher)

♦ Grinding (Ball mill)

♦ Classifying (Sprial classifier or High frequency vibrating screen)

♦ Ore separating ( Flotation machine/ Magnetic seperator/ Shaking table )

♦ Concentrating (Concentrator)

♦ Drying (Rotary dryer)

Part 2.  Main product pictures:

1. Primary crushing (Jaw crusher): coarse crushing raw material

2. Secondary crushing & Third crushing (Fine jaw crusher):

fine crushing the material which came out from primary or secordary crusher

3. Grinding (Ball mill ): for grinding crushed raw material to specific size powder

4. Classifying ( Spiral classifier): classifying the granule. The bigger granule will be send back to ball mill, and the suitable granule was sent to next step.

5. Iron removing separator (Magnetic separator): separating fine material from grinded raw material, this product is mainly used for removing iron or selecting iron from material.

6. Chemical separating (Flotation machine): separating fine material from grinded material. This product is used for selecting specific ore by using chemicals from raw material, such as gold, silver, copper, lead, zinc etc.

 7. Drying (Rotary dryer):drying material to dry powder

Part 3.  Ore Separating process:

1. Flotation separating process:

2. Magnetic separating process:

Part 4.  Our service:

 1. Pre-sale services:

   1>. Select proper equipment model;

   2>. Design and manufacture products according to clients' special requirement;

   3>. Arrange for visiting our factory, assist them to handle relative procedure, such as visa.

2. Services during the sale:

   1>. Make sure goods prepared within delivery time;

   2>. Pre-check and accept products ahead of delivery;

   3>. Prepare documents required to help customer pass customs clearance.

   4>. Help clients to make Project evaluation and feasibility analysis and draft solving plans.

3. After-sale services:

   1>. Assist clients to prepare for the first construction scheme;

   2>. Install, debug and examine the equipment;

  3>. Train technical personnel the first-line operators;

  4>. Provide technical exchanging

   5>. Offer spare parts at a best price for long term.

 Note: Responsible for handling other required matters conforming the state regulations.

Part 5.  About us:

We, Henan Zhongke Engineering & Technology Co., Ltd., are professional manufacturer which specialized in heavy equipment development and production. Our main products include mining equipment, ore dressing equipment, building material making equipment, such as various crushers, ball mill, magnetic separators, floation machine, rotary dryer, rotary kiln, cooling machine, bricks and blocks machines, cement and lime production line, AAC block line, ceramic sand production line, stone and sand production line etc., Our factory is located in Henan province, the base of china heavy equipment.

    We have more than 40 years experience in this field. Our high quality products, competitive price and excellent after-sales service had gained us good reputation in this field. We have brought together a number of scientific and technological elite. More than 500 employee in our factory with 20 senior engineers and more than 100 middling technicians. We have strong technical and resources support behind us.

    Ore dressing line is one of our main products. we can serve you the material analyse, process and plant design, and the complete set technology support.

We believe quality is the whole life of our company!

We sincerely welcome you to visit our factory!
