DC reactor elevator inverter for pump 7.5KW

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Hongkong/Shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	FRECON
Model Number	FR200	Output Power	Other, 0.4-600kw
Output Type	Triple	Size	from 168mm(D)116.6mm(W)186.6mm(H)
Weight	2.2kg~320kg	Input Voltage	0~380V
Output Voltage	0~Input Voltage	Type	Other, AC-DC-AC
Output Frequency	0.00~600.00Hz	Output Current	2.5~725A

Product Description

Specifications

output frequency:0-400Hz
Starting torque:0.5Hz,180% vector
Speed control ratio:1:100 (SVC)
Carrier frequency:1~15.0kHz

Product Description

FR200 Series sensorless vector control frequency inverter ac drive 220v/380v

I/O Features	Input Voltage Range	3-phase 380 V (-15%~+30%)
	Input Frequency Range	50Hz/60Hz,tolerance±5%
	Output Voltage Range	0~rated Input voltage
	Output Frequency Range	0.00~600.00 Hz,unit0.01Hz
I/O Terminals	Input Terminals	7 Digital Inputs, 1 high speed pulse;
	Input Terminals	3 Analog Inputs, VCI:-10V~10V, CCI2:0~10V or 0~20mA
	Output Terminals	2-way switch output terminal, which supports a maximum road speed 100kHz pulse output. 2 relay output terminals. 2 analog output terminal, and optional voltage and current.
	Communication Terminals	RS485 communication interface is optional, adopt Modbus-RTU communication mode.
Control Function	Control Mode	V/f control Sensor-less vector control 1 Sensor-less vector control 2
	Speed Adjusting Range	1:50 (V/f control) 1:100 (sensor-less vector control 1) 1:200(sensor-less vector control 2)
	Overload Capacity	150% Rated Current 60s,180% Rated Current 10s,200% Rated Current 1s
	Frequency given	digital setting, keyboard potentiometer setting, analog Voltage, given analog current reference pulse is given, the serial port is given, multi-speed given, PLC is given, the process PI D reference.
	Other Functions	Traverse Control Function
		PID Control Function
		Simple PLC,Multi-Steps Speed Control Function: 16 steps speed can be set.
		None-Stop when instantaneous power off.
		Speed Trace Function: Smoothly start the running motor.
		Automatic Voltage Regulation Functin (AVR):
		Up to 23 fault protections over current, over voltage, under voltage, over temperature, phase failure, overload etc.
Man-machine Interface	LED Display	Can display setting frequency, output frequency, output voltage, output current etc.
Man-machine Interface	Multi-function Key-press	The QUICK/JOG key-press can be used as multi-function key-press.
Environmental Constraint	Temperature	-10°C~+40°C
	Humidity	5~95%, no condensation
	Altitude	0~2000m De-rate 1%for every 100m when the altitude is above 1000 meters
	Vibration	Less than 5.9m/s2 (0.6g)
	Storage temperature	-20°C~+70°C
