EOC Slave Modem With WiFi

EOC Slave Modem With WiFi thumbnail-1
EOC Slave Modem With WiFi photo-1
US$ 1 - 32 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
photon
Model Number:
PTC1000-W1704
Contact Supplier Request Quote Chat Now
Shenzhen Photon Broadband Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name photon
Model Number PTC1000-W1704

PTC1000-W1704 EOC Slave



Description



PTC1000-W1704 adopts Athros chipset solution with 4FE ethernet ports and WiFidevice. It has high speed internet access and interactive TV on one cable for user. Four LEDs indicate link working status.



Data Features



      •  Compliant with HomePlug AV, IEEE 802.1q , IEEE 802.3, IEEE 802.3x/u
      • Support concentrated network platform of SNMP, remote management support
      • Port rate and MAC Address number limitation
      • TV Band 87MHz-860MHz, Date Band 7.5MHz-65MHz
      • Strengthened anti-jamming capability with OFDM (Orthogonal Frequency Division Multiplexing) and FEC (Forward Error Correction) technology
      • Supporting auto-configuration and manual configuration
      • High security and isolated between terminal equipments
      • doesn't destroy house or office original decoration
      • Remote Firmware Update of the EoC terminal
      • Higher sensitivity of RF receiver
      • LED indicate link working status
      • Using existing coaxial and
      • Lower power Consumption



Wifi Feachurs

      • IEEE 802.11n and 802.11b/g compliant
      • Up to 150Mbps in wireless N mode Wireless
      • Includes Advanced Encryption Standard (AES)
      • Surports IEEE 802.11g, 802.11b, 802.11i, 802.1X, 802.3, 802.3u, 802.3X,802.11n     standards .
      • Support 1-13 wireless channel
      • Wireless security :WEP,WPA-PSK,WPA2-PSK(AES,TKIP)and 64bit or 128bit WEP support
      • Support Multiple SSID, Hidden SSID and Wifi Protocol Setup (WPS)



Specifications



Parameter

Units

Specifications



Interface





PTC1000-W1704



standard Ethernet interface

PCS

4



RF interface

PCS

1



Data RF output

PCS

1



power input port

PCS

1



Bandwidth

Physics Bandwidth



500Mbps.



MAC Bandwidth



350Mbps



Light Indicator

Light Indicator



Link (Cable port)





ETH (Ethernet port)





Power



Others

WiFi speed

Mbps

150Mbps



WiFi Frequency Range

GHz

2.4GHz



RF Connector



F-type Female socket, metric



RF Output Impedance

Ω

75Ω



Power

V

External power DC12V 500mA



Power Consumption

W

<5W



RF Channel Frequency



7.5 ~65MHz



RF Output Power

dBuv

100-120dBu adjustble



RF Receive Sensitivity

dBM

-60dBM



Distance

M

>700M



Modulation Mode



OFDM 4096/1024/256/64/16/8-QAM, QPSK, BPSK ROB



Standard



IEEE802.3,IEEE 802.3u,802.1Q,802.1P ,IGM



Modify Reject Protocol



TDMA and CSMA/CAP



Encryption



128-bit AES



Dimension



158mm(L)x134 mm(W)x30 mm(H)



Operating temperature

℃

-30 ~60°C



Storage temperature

℃

-30 ~70°C



Operating humidity

RH%

20% ~85% non-condensing



Storage humidity

RH%

10% ~90% non-condensing



















Wifi Chip Solution







The Atheros AR9331 is a highly integrated and cost effective IEEE 802.11n 1x1 2.4 GHz Systemona-Chip (SoC) for wireless local area network (WLAN) AP and router platforms.



MIPS 24K processor operating at up to 400 MHz



DDR2:64MB;Flash:8MB .







Block Diagram:

EOC slave modem with WiFi



Standards:



--   IEEE802.11b



--   IEEE 802.11g



--   IEEE 802.11n







--   IEEE802.3



--   IEEE 802.3u



  • Surports 2.4GHz,Compatible with IEEE 802.11g, IEEE 802.11n, IEEE 802.11b Standards .
  • Surports 64/128/152-bit WEP, and 128 bit WPA standard(TKIP/AES), IEEE 802.1X .
  • Support SSID broadcast control and MAC address-based access control .
  • channels: 1-13 .
  • Frequency Range:2.412~2.472GHz .
  • Modulation schemes :BPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) .
  • PER: 135M:-65dBm@10%PER;65M:-65dBm@10%PER;54M:-68dBm@10%PER;11M:-84dBm@8% PER;6M:-88dBm@10% PER;1M:-90dBm@8%PER .
  • RF POWER :11n 12dBm 11g 13-15dBm, 11b 16-18dBm .
  • Antenna: Gain,5dbi .



WIFI SPECIFICATION:







Wireless

Frequency Range

2.412~2.472GHz

Wireless Data Rate

11n:

Bandwidth 40M:150, 135,121.5,108,81,54,40.5,27,13.5Mbps

Bandwidth 20M:72,65,58.5,52,39M,26,19.5,13,6.5 Mbps

11g:54/48/36/24/18/12/9/6Mbps

11b:11/5.5/2/1Mbps

Wireless Security

WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES)

64/128/152 bit WEP

SSID ON/OFF

MAC address filtering
