Help CenterGalvanized Corrugated Sheet/roofing Corrugated Plate (zinc/color-coated)
Related Products
-
Customized Steel Structure/Galvanized Steel Tower Supporting Engineering(Steel Frame Factory) for ConstructionNegotiableMOQ: 1 Metric Ton -
Livestock Industry Cattle Lying Bed With Hot Dip GalvanizedNegotiableMOQ: 1 Ton
-
New Design Cattle Free Stall With Hot Dip GalvanizedNegotiableMOQ: 1 Ton
-
Animal Husbandry Equipment Cattle Free Stall BeddingNegotiableMOQ: 1 Ton
-
High Quality Cattle Lying Bar, Dairy Farm EquipmentNegotiableMOQ: 1 Ton
Corrugated plate in galvanized or collor coated,was produced though the cold formed process to be different shapes.it was widly applied in construction,wearhouse,etc.With the high strength and lightly weight.very suitatble to afbrication.
Here below is the specification of galvanized corrugated sheet:
1.Thickness 0.2-1.5mm
2.Width:600-1250mm
3.Length: 1600mm-4000mm or according to customers' requests
4.Technique: Cold rolled
5.Surface treating: Hot dip Galvanized or Color coated
6.Packing: in bulk or container
Specifications:
| Galvanized corrugated sheets | ||
| 1 | Material | JIS G3302 SGCH(full hard);Zinc coating:60-120g/m2 |
| 2 | Physical properties | Tensile strength:220-550Mpa; |
| Yield strength:350Mpa; | ||
| Elongation: 10%-20%;Hardness>50 | ||
| 3 | Thickness | 0.13mm-0.8mm |
| 4 | Width after corrugated | 650mm-1150mm;Regular width:800mm, 840mm, 900mm |
| 5 | Length | 1600mm-4000mm or according to customers' requests |
| 6 | Wave | Wave height:18mm(+/-2)mm. |
| Wave distance:76.2mm (+/-3)mm. | ||
| 7 | Application | 1.Exterior decoration of buildings: Roof and wallboards of industrial, commercial,residential and public facilities. |
| 2.Interior decoration of buildings: Wallboards, ceiling boards,partition boards, fireproof doors | ||
| 3.Building accessories: Window panels, signboards. | ||
| 4.Home appliances: Oil/gas boilers, rice buckets, portable gas burners. | ||
| 8 | Advantages | according to customers'requirements. |
| 2.manufacture under complete quality control system--ISO9001. | ||
| 3.it is light,easy to be installed. | ||
| 4.many colors available,with elegant and noble looking.it is widely used in factories,hotels,exhibitions. | ||
| 5.eco-friendly material:can be uesd several times and can be recycled. | ||
| 6.shorter construction period,longer using times. | ||
Packing:
Our other product relatively:
Steel Profile: H-beam/ I-beam/Equal and unequal Angle/U Channel/Flat Bar
Steel Plate: Hot rolled coil/ Hot rolled checkered coil
Long Steel: Deformed Bar/ D-Bar Coil/Wire Rod
Steel Pipe: Seamless Pipe/Square-Round Pipe
Galvanzed Steel: Angle/channel/I-beam/ Round-Flat Bar/ Round-Square Pipe
Steel structure for solar energy system and construction structure
Located in the most convinent Tianjin Port,Tianjin Hengxing Group Company,which among the Most 500 powerful Chinese Private terterprises, we have our self-runned cold formed factory,welding factory and hot dip galvanziing factory. Affiliated to Hengxing Group, Lin Feng Trading is the export divison directly, we can produce and offer you quality galvanized or ungalvanized steel and other various steel related products.
Our advantages:
- We have our self-runned welding, hot-dipped galvanizing factory, and cold-formed factory, to make sure the price competively and all the steel structural components are all hot-dipped galvanized without corrosion.
- Location advantage: In the center of China's iron and steel industry, the transportation is convenient.
- Technology support: According to your drawing, our smart design ability can provide you improvement plan.
If you are intersted in our products, please contact us!
