Compact Tractor, 2WD, Diesel Power, Small Tractor

Compact Tractor, 2WD, Diesel Power, Small Tractor thumbnail-1
Compact Tractor, 2WD, Diesel Power, Small Tractor thumbnail-2
Compact Tractor, 2WD, Diesel Power, Small Tractor photo-1
Compact Tractor, 2WD, Diesel Power, Small Tractor photo-2
US$ 850 - 950 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Walking Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Yancheng Dayang Farm Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
compact tractor
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Walking Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 13.24kw
Certificate Other
Brand Name Huiyou
Model Number DF-12/12L; DF-15/15L; DF-18/18L; DF-20/20L
Place of Origin Jiangsu, China



Dong Feng  Walking Tractor / Power Tiller

Hand Tractor, Walking tractor, Power Tiller, Two Wheel Tractor

Diesel Engine Power, Evaporative / Radiator Cooling system

12 hp / 15 hp / 18 hp / 20 hp

HUIYOU   Brand

compact tractor





Product Description



1. Instruction of the walking tractor:

The tractor is featured by its simple and compact construction , reliability , long service life ,easy operation , ample output , light weight and high versatility This tractor is very suitable for use in paddy field , small dry field , orchards , vegetable gardens of hilly land with small inclination . It can be used for ploughing , rotary cultivating , harrowing in paddy field , harvesting , transportation ,etc .if suitable implements or accessories are attached . In addition , the tractor can be extensively used as a stationary power station for small scale drainage and irrigation , spraying , grain threshing , cottons ginning , flour milling , fodder cutting , etc.



2. Main descriptions:

Model:

DF-12

DF-15

DF-18

DF-20

Engine:

Model:

S195

ZS1100

ZS1105

ZH1110

Type:

1 cylinder, Horizontal, 4 cycle

Combustion System:

Swirl

Direct Inject

Bore × Stroke:

95 × 115 mm

100 × 115 mm

105 × 115 mm

110 × 115 mm

Displacement:

0.815 L

0.903 L

0.996 L

1.093 L

Compression Ratio:

22:1

20:1

17:1

17:1

Rated output/speed:

12hp / 2000 rpm

15hp / 2200rpm

18hp / 2200 rpm

20hp / 2200rpm

Max. output/speed:

14hp / 2000rpm

17hp / 2200rpm

20hp / 2200rpm

22hp / 2200rpm

Cooling System:

Evaporative / Radiator(as your requirement)

Lubrication System:

Combined pressure and splash

Starting Mothod:

Hand crank / Electric start (as your requirement)

Overall dimension:

2680 × 960 × 1250 mm

Wheel tread:

800, 740, 640, 580 mm

Tyre:

6.00 - 12

Ground clearance:

182 mm

Clutch type:

Two-disc, constant-contact, friction

Gear/Speed:

6 forward:

1.4 / 2.5 / 4.1 / 5.3 / 9.4 / 15.3 km/h

1.54 / 2.75 / 4.51 / 5.83 / 10.34 / 16.83 km/h

2 reverse:

1.1 / 3.8 km/h

1.2 / 4.18 km/h

Rotary Cultivator:

Model:

1GS9L-60

Tilling width:

600 mm

Blade No.:

18 tilling blades

Net Weight:

500 kg

505 kg

515 kg

525 kg

Packing method:

Wooden case / Veneer case / Steel frame / SKD

Packing Size:

1.16 × 1.1 × 1.1 m

Loading port:

Shanghai Port



Compact Tractor, 2WD, Diesel Power, Small Tractor



Standard configuration (packing list):



1. 12-20 hp diesel engine

2. Dong Feng type chassis and operation platform

3. 2 pcs, 6.00-12 type rubber driving wheel

4. 1GS9L-60 Rotary Cultivator with seat assembly



(optional implements: radiator cooling; motor start; different accessories)



Optional Accessories of Tractor

Compact Tractor, 2WD, Diesel Power, Small Tractor





Company Information

 Compact Tractor, 2WD, Diesel Power, Small TractorCompact Tractor, 2WD, Diesel Power, Small Tractor

Packaging & Shipping

 Compact Tractor, 2WD, Diesel Power, Small TractorCompact Tractor, 2WD, Diesel Power, Small Tractor





Certifications

Compact Tractor, 2WD, Diesel Power, Small Tractor



FAQ

1. How to get an accurate quotation?

    To get a quotation list, please send inquiry on Alibaba or send email to us directly. The email addresses are shown in the contact detail page.

     As we have different models and different implements, please indicate following details in your inquiry email,

       a)  Output (how many HP) or Model No.

       b)  Cooling system (evapoative / radiator)

       c)  Starting method (hand crank / motor start)

       d)  Order quantity!

   These are very important for providing you an accurate and favorable price.



2. What is the minimum order quantity?

     Our minimum order quantity is 2 sets in an order, please be sure that your order quantity is at least 2 sets.



3. About the shipment

     Usually if you didn't indicate the shipping requirement in the inquiry email, we will provide you FOB price which does't include shipping cost.

     If you need us ship the machine to your country, please also tell us the destination sea port.

     Due to the heavy weight of our machines, we can only arrange sea transportation for you



Thank you!
