Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor

Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor thumbnail-1
Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor thumbnail-2
Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor thumbnail-3
Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor photo-1
Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor photo-2
Mini Hand Tractor , Walking Tractor , Power Tiller , Small Hand Tractor photo-3
US$ 850 - 1,050 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Walking Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Yancheng Dayang Farm Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Walking Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 8.88kw
Certificate Other, SGS;ISO9002
Brand Name OEM
Model Number HY-121,HY-151,HY-181,HY-201
Place of Origin Jiangsu, China

mini hand tractor , walking tractor , power tiller , small hand tractor



mini hand tractor , walking tractor ,Power tiller,Small hand tractor,Cheap tractor

12 hp / 15 hp / 18 hp / 20 hp

HUIYOU   Brand





Product Description



1. Instruction of the walking tractor:

mini hand tractor,walking tractor,power tiller

The tractor is featured by its simple and compact construction, reliability, long service life,easy operation, ample output, light weight and high versatility . This tractor is very suitable for using in paddy field, small dry field, orchards, vegetable gardens of hilly land with small inclination. It can be used for ploughing, rotary cultivating , harrowing in paddy field, harvesting, transportation ,etc .if suitable implements or accessories are attached. In addition, the tractor can be extensively used as a stationary power station for small scale drainage and irrigation, spraying, grain threshing, cottons ginning, flour milling, fodder cutting, etc.



2. Main descriptions:

12hp / 15hp / 18hp / 20hp  tractor , walking tractor/power tiller



Model:

HY-121/121L

HY-151/151L

HY-181/181L

HY-201/201L

Engine:

Model

ZS195/ZS195NL

ZS1100/ZS1100NL

ZS1105/ZS1105NL

ZS1110/ZS1110NL

Type

1 - cylinder, Horizontal, 4- cycle

Combustion System

Direct Injection

Bore × Stroke

95 × 115 mm

100 × 115 mm

105 × 115 mm

110 × 115 mm

Rated output/speed

12hp / 2000 rpm

15hp / 2200rpm

18hp / 2200 rpm

20hp / 2200rpm

Cooling System

Evaporative / Radiator

Overall dimension

(L x W x H)

2680 × 960 × 1250 mm

Wheel tread

800, 740, 640, 580 mm

Tyre

6.00 - 12

Ground clearance

182 mm

Clutch type

Two-disc, constant-contact, friction

Speed

6 forward

1.40 / 2.50 / 4.10 / 5.30 / 9.40 / 15.30 km/h

1.54 / 2.75 / 4.51 / 5.83 / 10.34 / 16.83 km/h

2 reverse

1.10 / 3.8 km/h

1.20 / 4.18 km/h

Rotary Cultivator

Model

1GS9L-60

Tilling width

600 mm

Blade Qty.

18 pcs

Net Weight

500 kg

505 kg

515 kg

525 kg

Packing method(Optional)

Wooden case ;Veneer case ; Nude(Shipping by SKD)

Packing Size

1.16 × 1.10× 1.10 m











mini hand tractor , walking tractor , power tiller , small hand tractor



Standard configuration (packing list):



1. Diesel engine ;

2. Dong Feng type chassis ;

3. 1GS9L-60 Rotary Cultivator;

4. Rear wheel and seat assembly ;

5. Tool bag.





Optional Implement of Tractor

mini hand tractor , walking tractor , power tiller , small hand tractor





Company Information

 mini hand tractor , walking tractor , power tiller , small hand tractormini hand tractor , walking tractor , power tiller , small hand tractor

Packaging & Shipping

 Shipment of packed (2 kinds: wooden case, veneer case )mini hand tractor , walking tractor , power tiller , small hand tractor

Shipment of SKD (semi-knocked down)

mini hand tractor , walking tractor , power tiller , small hand tractor



Certifications

mini hand tractor , walking tractor , power tiller , small hand tractor






FAQ

1. How to get an accurate quotation?
To get a quotation list, please send inquiry on Alibaba or send email to us directly. The email addresses are shown in the contact detail page.
As we have different models and different implements, please indicate following details in your inquiry email,



a) Output (how many HP) or Model No.
b) Cooling system (evapoative / radiator)
c) Starting method (hand crank / motor start)
d) Order quantity!



These are very important for providing you an accurate and favorable price.

2. What is the minimum order quantity?
Our minimum order quantity is 2 sets in an order, please be sure that your order quantity is at least 2 sets.

3. About the shipment

Usually if you didn't indicate the shipping requirement in the inquiry email, we will quote on FOB price which does't include shipping cost.

If you need us ship the machine to your country, please also tell us the destination port.


Thank you!

Best wishes.
