1.A-Starjet 5L DX5 Printing Machine:
High Performance, High Quality Eco-Solvent Printers
A-Starjet 5L inkjet printing machines go beyond extraordinary to deliver an awe-inspiring range of applications and versatility. Gamut-extending eco solvent inks enable you to accomplish anything from fine art reproduction,
wall décor and stunning backlits, to vehicle wraps and outdoor displays. Using the
A-Starjet 5L inkjet printing machines’ superb quality, color fidelity, throughput and flexibility you’ll
go beyond the expected to capture more wallet share and deliver whatever your customers can imagine.
2. A-Starjet 5L Eco-solvent Printing Machine
Go Beyond Conventional
1. Micro Piezo Printing Technology
The DX 5 Micro Piezo print head can reach resolution of 1440 dpi. Its extremely fine ink droplets are able to fully reflect the rich details of the pictures, and to fulfill the requirement of short viewing range. It suits both water-based dye and eco-solvent pigment ink and widely used in many fields. And it can offer one or two years’ service life.
2. Variable Ink Droplets Technology
The variable ink droplets technology can project micron grade ink drops of various sizes. Ink drops are between 1.5pl to 21 pl to produce best color results, smooth gradients, and fine details.
3. Progressive Pass Compensation Technology
The progressive pass compensation technology is used to remove the grinning of white ground or edge overlap ( banding lines), which is usually caused by mechanical inaccuracy, and further improve the yield and save the cost.
4. Stochastic Ink-droplet Distribution
With the technology of stochastic ink-droplet distribution, some problems caused by nozzle clog, like white strips, can be resolved. Even with 15% nozzle clogged, A-Starjet series printers can still ensure the printing quality.
5. High printing precision,high stability with competitive price
A-Starjet 5.0 printers supply the printings in high quality with high performance-cost,enough to contend with many famous-brand printers,and the complex head adjustment can be avoided.They are easy to operate and maintain.Easy to calibrate printing head.more stable.
6. New Mechanical Structure
It includes a linear guide drive structure, XY axis coding system, multi-channel ink supply system, heating system on both front and rear platform, media absorption system, and print heads auto-service station. Besides, it also has a paper handling system that can bear loads up to 70kg, and a drying system. The printer weights about 220kg in total and 90% of its components are very durable.
7. USB 2.0, Bundled with RIP
USB 2.0 interface supports high speed data transmission and collaborative operation. It greatly enhances the printing performance. iPrint 3 RIP software fully complies with ICC color management standard. And it supports automatic image tiling and composition, linear color adjustment and inking management, etc. With the optional PS components, it is also able to process Adobe Postscript files.
8. Wide Range of Media Compatibility
The height of print head is adjustable between 2 to 5mm, up to 330cm media in width. The printer can use many kinds of compatible ink, like eco-solvent or water-based ink, also pigment or dye ink, as well as sublimation ink. Various of media can be used, including self-adhesive paper, PP, backlit film, canvas, non-woven fabric, chemical fabric, PU leather, micro fibre, leather and etc.
3. Details of 3.2m Eco-solvent Printing Machine with DX5 Print Head
| Item | A-Starjet 5L Printing Machine |
| Printing Technology | DX5 micro piezo technology |
| Print Head | Two DX5 drop-on-demande micro piezo print heads |
Number of Nozzles |
2880 Nozzles (2 Heads) |
Ink Color |
4 Colors:Cyan, Magenta, Yellow, Black |
Resolution |
1440dpi(max) |
Height of Print Head |
2-5mm |
Size of Ink Droplet |
1.5-21pl |
Printing Width |
3.2m |
Media Width |
130"3300mm(max) |
Speed |
Production mode: 344 sq.ft.(32 sqm)per hour |
Standard mode: 172 sq.ft.(16 sqm)per hour | |
Photo mode: 134 sq.ft.(12.5 sqm)per hour | |
Media Take up |
Automatic Take-up System(optional) |
Media Feeder |
Automatic feeder |
Media Type |
Self-adhesive paper, PVC, mesh fabric, textile, PVC flex banner, adhesive vinyl, photo paper, PP, backlit film, canvas, non woven fabric, PU leather, micro fibre, leather, etc. |
Media Payload |
200kgs(max) |
Heating System |
The heaters for front and rear platform separately. PID temperature control Temperature range: room temperature to 80℃ |
Drying System |
External fans |
Ink Type |
Eco-solvent pigment ink, eco-solvent dye ink, water-based dye ink, sublimation ink |
Ink Cartridge |
8 × 350ml Cartridges |
RIP Software RIP |
IPrint 3.0(English version) |
Supported image format: TIFF, JPEG, and other common image formats | |
Postscript file process(optional) | |
Control Software |
A-Starjet control software(English version) |
Interface |
USB port ver2.0 |
Power Voltage |
AC 110-220V 50-60Hz or 220-240V 50-60Hz |
Printer Dimension |
W4300*D900*H1250mm( bracket included ) |
Packing Dimension |
W4350*D930*H730mm( bracket included ) |
Net Weight |
320KGS( bracket included ) |
Gross Weight |
550KGS( bracket included ) |
5. What you can do with the
3.2m Eco-solvent Printing Machine with DX5 Print Head
With eco solvent inks:
- Signage
- Vehicle graphics
- Point-of-purchase displays
- Banners
- Posters
- Exhibition graphics
- Window clings
- and more…
6. Highlights of 3.2m Eco-solvent Printing Machine with DX5 Print Head
- Print Head: 2 pcs Epson DX5 print head, each print head has 1440 nozzles. Currently we have decrypted encrypted DX5 print heads so we can guarantee the supply of DX5 print heads.
- Printing Width: the maximum width can be up to 3.2M / 126 Inch.
- The only step need for adjust the print heads is to insert the print head into the carriage. It doesn’t need to be adjusted for several times and dairy maintenance is quite easy and can be learned quickly.
- Eco-solvent ink: it is eco-friendly, the smell of the ink is light which is suitable to use the printing media in indoor and outdoor both.
- Competitive price can be available.
- Short lead metimes after about 7days we will arrange the shipment when order confirmed.
- After-sales service can be supported.our engineers are always online and willing to reply you any question about our printers,butalso they are available to go to your factory to teach you how to use our printers and keep our printers properly.
7. Packing of 3.2m Eco-solvent Printing Machine with DX5 Print Head
Reasonable Price
- Directly cooperate with R&D factory.
Comprehensive Guatantee Term
- Print heads are guaranteed when A-Starjet ink being used
- Motors are guaranteed for 6 months
- Printer's boards are guranteed for 15 months
- Counting from the day printer leaves factory
- Within guarantee time, send spare parts in advance and we'll cover all the freight
- After guarantee time, repair fee will be charged
Comfortable After-Sale Service
We are a highly efficient and experienced team.
- Online support Skype, Whats app, TeamView, Youtube, etc.
-
Official Service time from Monday to Saturday:
8:30am to 5:30pm(GMT +8), by experienced Engineers/Sale - 24 hours self-service available by Arthur's Youtube channel.
- All printer, parts in stock, able to ship out on any workday.
- Life-time free technical support from A-Starjet factory by engineers who have worked for A-Starjet for 6-7 years.
- Onsite Service is acceptable
We have expos in Shanghai, Guangzhou, Dubai, Italy, Indonesia..............
Shanghai
Great products with awesome quality!
You deserve it!
