Help CenterHigh Alumina Ceramic Lined Three Links, Alumina Ceramic Lined Multi-way Tubes
Related Products
-
Alumina Ceramic Lined T-piece, Alumina Ceramic MultipassNegotiableMOQ: 5 Pieces -
High Quality Ceramic Mosaics Using For Pulley LaggingUS$ 1,000 - 1,000MOQ: 2 Tons
-
High Wear Resistant Alumina Ceramic Lined Bend, Alumina Ceramic Lined TubeNegotiableMOQ: 5 Pieces
-
Alumina Ceramic Lined T-piece, Ceramic Lined Pipe, Alumina Ceramic Lined MultipassNegotiableMOQ: 40 Pieces
-
Thickening-Classifying Cyclone Underflow Box, Alumina Ceramic Lined Cyclone PartNegotiableMOQ: 1 Piece
1>Specifications
We are factory and have own design department, could meet customer's any needs.welcom to our visit our plant.
1. Alumina is a cost effective and widely used material in the family of engineered ceramics. Alumina ceramics have
been developed and optimised for maximum wear resistance and corrosion resistance. A high density, diamond like hardness, fine grain structure and superior mechanical strength are the unique properties that make it the material of
choice for a wide range of demanding applications.
2.Ceramic has uses similar to Cast Basalt but it has greater resistance to wear in high velocity applications and impact resistance in extreme dynamic systems
3.
Main Properties of Ceramic | |
Item |
Index |
Content of Alumina |
≥92% |
Density of ceramic liner |
≥3.60 g/cm3 |
Rockwell Hardness |
≥80 HRA |
Impact Strength |
≥850 Mpa |
Bending Strength |
≥290MPa |
Breaking Temper |
≥4.8MPa·m1/2 |
Coefficient of Linear Thermal Expansion |
20W/m.K |
4. CNER provides its customers with the full range of abrasion resistant lined pipework including Straight Pipe, Bends and Elbows, Reducers, Tees and Y-pieces.(See diagrams below)
Linings
Ceramic tiles range in thickness from 1/4” to 2”. Basalt cylinders range in size from 2” I.D. up to 24” I.D. with athickness of 3/4” to 1”. Larger basalt lined diameters are possible using basalt radial tile ranging in thickness from 7/8” to 2”.
Flanges
As well as our standard Fixed and Rotating Flanges, CNER also supplies Adaptor Flanges, Dresser
Couplings and Victaulic Couplings to suit our customers’ applications and requirements.
Finish
Surface coating is typically a red oxide primer. Other finishes are available to suit our customers’ specific
requirements.
2>Industries served:
• Power Industry(Coal fired&Biomass)
• Coal Mine and Preparation Plants
• Cement &Asphalt Processing
• Pulp&Paper Mills
• Water&Waste Water Treatment
• Mineral Processing
• Steel Industry
3>Our Main Products:
4> Certification:
5. FAQ
Q: 1. Can I have a sample order?
A:Yes,we welcome sample order to test the product quality. Kindly let us know the detailed information
Q: 2. Do you have any MOQ limit?
A:According to different type of products the MOQ limit is different.we looking forward to your inquiry.
Q:3. What is the lead time?
A: Mass production will take 15-25days, it will also depends on the order volume.
Q:4.How about the quality of your products?
A: All of our products are conforms to the strict quality control during each processing phase.Also we have strict quality inspection procedure.
Q: 5. Can we visit your company?
A: No problem,we welcome to your arrival at any time.
