MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor

MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor thumbnail-1
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor thumbnail-2
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor thumbnail-3
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor thumbnail-4
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor thumbnail-5
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor photo-1
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor photo-2
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor photo-3
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor photo-4
MS Disc Valve Motor Compact in Design With Disc Valving and Roller Type Stator and Rotor Hydarulic Motor photo-5
US$ 95 - 145 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Type:
Hydraulic Motors
Model Number:
oms
Brand Name:
tpf
Contact Supplier Request Quote Chat Now
Danyang Titan Power Fluid Component Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Hydraulic Motors
Model Number oms
Brand Name tpf
Place of Origin Jiangsu, China

OMS series hydraulic motor which  replace danfoss hydraulic MS  disc valve motor  compact in design with disc valving and roller type stator and rotor hydarulic motor motor



      The disc valve Geroler technology, which has rollers incorporated into the internal fixed gear ring, allows for higher flows and higher pressures than the spool valve technology, provide smooth and reliable operation and high efficiency . we can produce many typs hydraulic motor which replace danfoss hydraulic motor



DANFOSS

CHAR-LYNN –EATON CODE

M+S

BMM series like OMM series

BMPH series like H (101)series

BMM series like MM/MLHM series

BMP series like OMP series

BMRS series like R (103)series

BMP series like MP/MLHP series

BMR series like OMR series

BMSE series like 2k (104)series

BMR series like MR/MLHR series

BMS series like OMS series

BMTE series like 4k(109) series

BMS series like MS/MLHS series

BMT series like OMT series

BMTE series like 6K(112) series

BMT series like MT/MLHT series

BMV series like OMV series

BMVE series like10K(119) series

BMV series like EMV/MLHV series



MS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motor



Type BMS BMS BMS BMS BMS BMS BMS BMS
80 100 125 160 200 250 315 375
Displacement (cm3/rev.)  80.6  100.8  125  157.2  200  252 314.5  370
Max. speed   (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque     (N•m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output    (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
ure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
 Max. flow      (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max.inlet pressure  (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight    (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6





Options   Application:
- Model - Disc valve, roll-gerotor;   • Skid-steer attachments
- Flange and wheel mount;   • Swing motors
- Shafts - straight, splined and tapered;   • Brush cutters & Mowers
- Metric/UNC and BSPP ports;   • Harvesting equipment
-Side and rear ports   • Directional boring
- Motor with BK2 Brake;   • Winch
-Motor with Drum Brake   • Auger
- Color-Blue, grey ,black ,yellow ;











DANFOSS CODE 80 100 125 160 200 250 315 400 500
151F 151-0500 151-0501 151-0502 151-0503 151-0504 151-0505 151-0506 151-0605 -
151F 151-2200 151-2201 151-2202 151-2203 151-2204 151-2205 151-2206 151-2261 151-2268
151F 151-0507 151-0508 151-0509 151-0510 151-0511 151-0512 151-0513 - -
151F 151-2207 151-2208 151-2209 151-2210 151-2211 151-2212 151-2213 151-2262 151-2269
151F 151-0514 151-0515 151-0516 151-0517 151-0518 151-0519 151-0520 - -
151F 151-2214 151-2215 151-2216 151-2217 151-2218 151-2219 151-2220 151-2264 151-2270
151F 151-0560 151-0561 151-0562 151-0563 151-0564 151-0565 151-0566 - -
151F 151-0542 151-0543 151-0544 151-0545 151-0546 151-0547 151-0548 - -
151F 151-2300 151-2301 151-2302 151-2303 151-2304 151-2305 151-2306 151-2307 151-2345
151F 151-2316 151-2317 151-2318 151-2319 151-2320 151-2321 151-2322 151-2323 151-2347
151F 151-2308 151-2309 151-2310 151-2311 151-2312 151-2313 151-2314 151-2315 151-2346
151F 151-2324 151-2325 151-2326 151-2327 151-2328 151-2329 151-2330 151-2331 151-2348
151F 151-2332 151-2333 151-2334 151-2335 151-2336 151-2337 151-2338 151-2339 151-2349
151F 151-2377 151-2378 151-2379 151-2380 151-2381 151-2382 151-2383 151-2384 151-2385
151F 151-2368 151-2369 151-2370 151-2371 151-2372 151-2373 151-2374 151-2375 151-2376
151F 151-2359 151-2360 151-2361 151-2362 151-2363 151-2364 151-2365 151-2366 151-2367
151F 151-2350 151-2351 151-2352 151-2353 151-2354 151-2355 151-2356 151-2357 151-2358
151F 151-2395 151-2396 151-2397 151-2398 151-2399 151-2400 151-2401 151-2402 151-2403
151F 151-2413 151-2414 151-2415 151-2416 151-2417 - - - -
151F 151-0521 151-0522 151-0523 151-0524 151-0525 151-0526 151-0527 151-0610 -
151F 151-2235 151-2236 151-2237 151-2238 151-2239 151-2240 151-2241 151-2265 151-2266
151F 151-0528 151-0529 151-0530 151-0531 151-0532 151-0533 151-0534 151-0609 -
151F 151-2242 151-2243 151-2244 151-2245 151-2246 151-2247 151-2248 151-2263 151-2267
151F 151-0535 151-0536 151-0537 151-0538 151-0539 151-0540 151-0541 151-0608 -

 MS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motorMS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motor



 MS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motorMS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motor

MS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motorMS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motor

 MS disc valve motor compact in design with disc valving and roller type stator and rotor hydarulic motor
