BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor

BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor thumbnail-1
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor thumbnail-2
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor thumbnail-3
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor thumbnail-4
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor thumbnail-5
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor photo-1
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor photo-2
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor photo-3
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor photo-4
BMR Series Shaft Distribution Flow of Reliable Quality Gerolor Gear Set Orbital Hydraulic Motor photo-5
US$ 60 - 76 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Type:
Hydraulic Motors
Model Number:
BMR
Brand Name:
tpf
Contact Supplier Request Quote Chat Now
Danyang Titan Power Fluid Component Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Hydraulic Motors
Model Number BMR
Brand Name tpf
Place of Origin Jiangsu, China



 BMR series hydraulic motor



    One type of LSHT motor,which can replace Danfoss OMR series ,M+S MR series White,Eaton ect.

    which adapt the Gerotor gear set design improves mechanical efficiency, provide reliable leak-free performance and smooth operation.Especially at start-up and low speed conditions.





BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor





Type  BMR  BMR  BMR  BMR  BMR  BMR  BMR  BMR  BMR  BMR
36 50 80 100 125 160 200 250 315 375
Displacement (cm3/rev) 36 51.7 81.5 102 127.2 157.2 194.5 253.3 317.5 381.4
Max. speed  (rpm) cont. 1250 960 750 600 475 378 310 240 190 155
int. 1520 1150 940 750 600 475 385 300 240 190
Max. torque
(N•m) 		cont. 72 100 195 240 300 360 360 390 390 365
int. 83 126 220 280 340 430 440 490 535 495
peak 105 165 270 320 370 460 560 640 650 680
Max. output (kW) cont. 8.5 9.5 12.5 13 12.5 12.5 10 7 6 5
int. 9.8 11.2 15 15 14.5 14 13 9.5 9 8
Max. pressure drop(Mpa) cont. 14 14 17.5 17.5 17.5 16.5 13 11 9 7
int. 16.5 17.5 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max.flow  (L/min) cont. 45 50 60 60 60 60 60 60 60 60
int. 55 60 75 75 75 75 75 75 75 75
Weight    (kg) 6.5 6.7 6.9 7 7.3 7.6 8 8.5 9 9.5





Specifications:   Applications:
- Model - Spool valve, roll-gerotor;   • Construction equipment
- Flange –Rhomb and Square flange;   • Agricultural equipment
- Motor with needle bearing;   • Material handling & Lifting equipment
- Shafts - straight, splined and tapered;   • Food industries
- Shaft seal for high and low pressure;   • Conveyors ,Lawn and turf equipment
- Three ports - Metric /UNC and BSPP;   • Marine equipment
- Color-Blue, grey ,black ,yellow ;
- motors with integrated bake :BK2 serie




BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor

 BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor

BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic MotorBMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic MotorBMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic MotorBMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic MotorBMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic MotorBMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor

Our hydraulic motor can replace below Danfoss OMR sereis motor :



CODE
  Displacement(cc)
code 50 80 100 125 160 200 250 315 375
151- 151-0410 151-0411 151-0412 151-0413 151-0414 151-0415 151-0416 151-0417 151-0418
151- 151-0710 151-0711 151-0712 151-0713 151-0714 151-0715 151-0716 151-0717 151-0718
151- 151-0400 151-0401 151-0402 151-0403 151-0404 151-0405 151-0406 151-0407 151-0408
151- 151-0700 151-0701 151-0702 151-0703 151-0704 151-0705 151-0706 151-0707 151-0708
151- 151-7240 151-7241 151-7242 151-7243 151-7244 151-7245 151-7246 151-7247 151-7248
151- 151-0420 151-0421 151-0422 151-0423 151-0424 151-0425 151-0426 151-0427 151-0428
151- 151-0720 152-0721 152-0722 152-0723 152-0724 152-0725 152-0726 152-0727 152-0728
151- 151-7250 151-7251 151-7252 151-7253 151-7254 151-7255 151-7256 151-7257 151-7258
151- 151-0248 151-0242 151-0243 151-0208 151-0244 151-0245 151-0247 151-0246 151-6294
151- 151-0265 151-0266 151-0267 151-6295 151-0268 151-0269 151-0271 151-0270 151-6296
151- 151-6010 151-6011 151-6012 151-6013 151-6014 151-6015 151-6016 151-6017 151-6018
151- 151-6000 151-6001 151-6002 151-6003 151-6004 151-6005 151-6006 151-6007 151-6008
151- 151-6110 151-6111 151-6112 151-6113 151-6114 151-6115 151-6116 151-6117 151-6118
151- 151-6210 151-6211 151-6212 151-6213 151-6214 151-6215 151-6216 151-6217 151-6218
151- 151-7260 151-7261 151-7262 151-7263 151-7264 151-7265 151-7266 151-7267 151-7269
OMR motors with corrosion resistant parts
151- 151-1231 151-1232 151-1233 151-1238 151-1234 151-1235 151-1236 151-1237 151-1243
OMR motors with needle bearings
151- 151-6380 151-6381 - 151-6383 151-6384 151-6385 151-6386 151-6387 151-6388
151- 151-6300 151-6301 151-6302 151-6303 151-6304 151-6305 151-6306 151-6307 151-6308
151- 151-6430 151-6431 151-6432 151-6433 151-6434 151-6435 151-6436 151-6437 151-6438
OMR motors with integratated brake
151- - 151-6461 151-6462 151-6463 151-6464 151-6465 151-6466 151-6467 151-6468
OMR motors with integratated brake and needle bearings
151- - 151-6471 151-6472 151-6473 151-6474 151-6475 151-6476 151-6477 151-6478
151- - - 151-6442 151-6443 151-6444 151-6445 - - -



 BMR Series Shaft distribution flow of reliable quality gerolor gear set Orbital hydraulic Motor
