5.4 Inch 240x64 T6963 Graphic Lcd Module
US$ 1 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Huayuan
Model Number:
GH24064-5401
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Transmissive STN COB 240x128 Graphic Lcd ModuleUS$ 1 - 50MOQ: 1 Piece -
320x240 Dot Matrix Lcd Module Lvds 5.7 Inch With NT7701US$ 1 - 40MOQ: 100 Pieces
-
3.5 Inch COB STN Lcd Module Hdmi With KS0107 ControllerUS$ 1 - 50MOQ: 1 Piece
-
5.7inch Graphic 320x240 Dot Matrix Projector Lcd ModuleUS$ 1 - 40MOQ: 100 Acres
-
128x64 2.5 Inch Cog Lcd ModuleUS$ 1 - 50MOQ: 1 Piece
Place of Origin
Hunan, China
Brand Name
Huayuan
Model Number
GH24064-5401
Type
COB
Specifications
240x64 t6963 graphic lcd modulecustomized product acceptable
Rohs compliance available
OEM Product Design / Production
The module datasheet
5.4 inch 240x64 t6963 graphic lcd module
| Model: | GH24064-5401 |
| Construction | COB |
| Display Type | STN,Negative or Positive ,Transmissive |
| Operating Voltage (VDD) | 3.3V,5V |
| Backlight Voltage(VBL) | 3.3V,5V |
| Operating Temperature (degree Celsius) | -20~70 |
| Storage Temperature (degree Celsius) | -30~80 |
| Viewing Direction | 06:00 |
| Dot Matrix | 240*64 |
| Viewing Area | 132.00*39.00 |
| Active Area | 127.16*33.88 |
| Outline Dimension | 180.00*65.00*12.51 |
| Controller | T6963 |
| Backlight | LED,Y-G,White |
The Layout Drawing
The Pin Definition
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 |
| GND | VSS | VDD | V0 | RS | R/W | CS | CD | NC | RST |
| 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 |
| D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | FS | VLCD |
