Specifications
Original New FortiGate-30D Fortinet Security Appliance FG-30DFortinet Security Appliance
FortiGate-30D
FB-30D ...
The FortiGate/FortiWiFi-30 series are very small, all-in-one Network Security Appliances that deliver Fortinet’s Connected UTM solution. With Connected UTM you get a single device that integrates comprehensive Enterprise-grade Network Security protection with a broad range of Wired and Wireless Connectivity options.
Connected UTM simplifies your network and makes it easier for your IT staff to manage your security and infrastructure while lowering your TCO.
Whether you need to secure a single home office or centrally deploy security across hundreds of small remote locations, these devices deliver network security, connectivity and performance at an attractive, entry-level price.
- Comprehensive network security, including Application Control, IPS, Advanced Antimalware, Web Filtering and VPN
- Simple per-device pricing eliminates the need to count users or license additional modules.
- Optional Power over Ethernet (PoE) support enables you to connect Wireless Access Point, 3G4G Extenders, VoIP Handsets and IP Cameras to your network security platform and away from power supplies.
Connected UTM optimizes your complex network and makes it easier for your IT staff to improve your security, simplify your infrastructure, and lower your TCO.
| FortiGate Model | FortiGate-30D | FortiWiFi-30D |
|---|---|---|
| Hardware Specifications | ||
| GbE RJ45 WAN Ports | 1 | 1 |
| GbE RJ45 Switch Ports | 4 | 4 |
| Wireless Interface | N/A | 802.11 a/b/g/n |
| USB Ports (Client / Server) | 1/1 | 1/1 |
| System Performance | ||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 800 Mbps | |
| Firewall Latency (64 byte UDP packets) | 8 μs | |
| Firewall Throughput (Packets Per Second) | 1.2 Mpps | |
| Concurrent Sessions (TCP) | 200,000 | |
| New Sessions/Sec (TCP) | 3,500 | |
| Firewall Policies (Max) | 5,000 | |
| IPSec VPN Throughput (512 byte packets) | 350 Mpbs | |
| Gateway-to-Gateway IPSec VPN Tunnels | 20 | |
| Client-to-Gateway IPSec VPN Tunnels | 250 | |
| SSL-VPN Throughput | 25 Mbps | |
| Concurrent SSL-VPN Users (Recommended Max) | 80 | |
| IPS Throughput | 150 Mbps | |
| Antivirus Throughput (Proxy Based / Flow Based) | 30 / 40 Mbps | |
| Max Number of FortiTokens | 100 | |
| Max Number of Registered FortiClients | 10 | |
| Dimensions | ||
| Height x Width x Length | 1.38 x 7.17 x 5.24 in (35 x 182 x 133 mm) | |
| Weight | 0.7 lbs (0.3 kg) | |
| Form Factor | Desktop | |
| Environmental | ||
| Power Required | 100 - 240 VAC, 50 - 60 Hz | |
| Max Current | 110 V / 0.6 A, 220 V / 0.3 A | |
| Power Consumption (AVG / Max) | 10 W / 12 W | 11.6 W / 14 W |
| Heat Dissipation | 41 BTU / h | 48 BTU / h |
| Operating Temperature | 32 - 104 °F (0 - 40 °C) | |
| Storage Temperature | -31 - 158 °F (-35 - 70 °C) | |
| Humidity | 20 to 90% non-condensing | |
| Compliance & Certifications | ||
| Compliance | FCC Part 15 Class B, C-Tick, VCCI, CE, UL/cUL, CB | |
| Certifications | ICSA Labs: Firewall, IPSec, IPS, Antivirus, SSL VPN | |
-
