Specifications
Made of Aluminum alloy liner, high quality carbon fiber and glass fiber which imported from JapanAdvantage:
Our CNG cylinder type is made of Aluminum alloy liner, high quality carbon fiber and glass fiber which imported from Japan. The cylinder offers advantages of low temperature toughness, fatigue resistance, low weight and high safty. Compared to the CNG cylinder Type 2, CNG cylinder Type 3 is 50% lighter in weight.
Worldwide exported:
We are professional cylinder manufacturer which have produced CNG cylinders for more than 10 years,
our production have been exported to North America, South America, Canada, Russia, Central Asia, South Asia, Europe and win favourable evaluation from our customers.
Applications:
Out CNG cylinder Type 3 is used for store natural gas in a wide variety of natural gas powered bus and Taxi.
Standard:
Q/CLD004-2009
Model list for Carbon fiber cylinders
Model |
Capacity(L) |
Weight(kg) |
Diameter(mm) |
Length(mm) |
Working Pressure |
CNG3-345-50-20A |
50 |
23.3 |
φ345 |
790 |
20 |
CNG3-345-70-20A |
70 |
30.6 |
φ345 |
1040 |
20 |
CNG3-345-80-20A |
80 |
34 |
φ345 |
1165 |
20 |
CNG3-345-90-20A |
90 |
37.3 |
φ345 |
1290 |
20 |
CNG3-345-100-20A |
100 |
40.6 |
φ345 |
1415 |
20 |
CNG3-404-70-20A |
70 |
32.4 |
φ404 |
805 |
20 |
CNG3-404-80-20A |
80 |
35.5 |
φ404 |
895 |
20 |
CNG3-404-90-20A |
90 |
38.6 |
φ404 |
985 |
20 |
CNG3-404-100-20A |
100 |
41.8 |
φ404 |
1075 |
20 |
Pictures:
