Fully Wrapped Carbon Fiber Aluminium Lined Cylinder

Fully Wrapped Carbon Fiber Aluminium Lined Cylinder thumbnail-1
Fully Wrapped Carbon Fiber Aluminium Lined Cylinder photo-1
US$ 95 - 1,600 MOQ: 30 Pieces
Key Specifications
Get Latest Price
Material:
Aluminium
Use:
Industrial Gas
Pressure:
High
Contact Supplier Request Quote Chat Now
Shenyang Gas Cylinder Safety Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
DALIAN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Aluminium
Use Industrial Gas
Pressure High
Place of Origin Liaoning, China
Brand Name CLD
Model Number FQC

Specifications

1.Material:high quality aluminum alloy 6061
2.Service pressure:20~30 MPa
3.Capacity:0.45~50 L
4.Diameter:60~352 mm

 Our advantages:

  • China's biggest aluminum and aluminum carbon composite cylinders manufacture.
  • Cylinders are made by high strength aluminum or aluminum & carbon fiber, thus the weight is 40%~70% lighter than convention steel cylinder.
  • Advanced construction and producing technology provide long working duration and high safety factor.
  • Cylinders can be made to many safety standards all over the word, such as TPEP, CE, etc.

Carbon wrapped  cylinder:

  • Winding layers: imported superior quality carbon fibers, epoxy and other materials.
  • Manufacturing procedure: punching drawing, heat treatment,CNC flow forming spinning and inner surface treatment.
  •  Wide range of sizes and capacities.

 Fully-wrapped composite cylinder:

  • Available in carbon-wrapped and fiberglass-wrapped models.
  • Manufactured to all recognized international standards.
  • Most compact, lightest-weight cylinders available up to70 percent light than steel cylinders.
  • Minimum burst  pressure tested to more than 3 times service pressure without failure.



Cylinder specification:

Specifications Diameter Water capacity Length Empty weight Working pressure
mm in lts cu in mm in kgs lbs bar psi
FQC60-0.45-30 60 2.36 0.45 27.45 280 11.02 0.5 1.10 300 4350
FQC60-0.5-30 0.5 30.50 310 12.20 0.6 1.32
FQC100-1.2-20 100 3.94 1.2 73.20 280 11.02 0.9 1.98 200 2900
FQC101-1.5-30 101 3.98 1.5 91.50 324 12.76 1.30 2.87 300 4350
FQC108-1.5-20 108 4.25 270 10.63 0.9 1.98 200 2900
FQC113-1.6-20 113 4.45 1.6 97.60 268 10.55
FQC113-2.0-20 2 122.00 320 12.60 1.4 3.09
FQC101-2.0-30 101 3.98 405 15.94 1.6 3.53 300 4350
FQC116-2.0-20 116 4.57 292 11.50 1.4 3.09 200 2900
FQC118-2.0-30 118 4.65 330 12.99 1.6 3.53 300 4350
FQC120-2.2-20 120 4.72 2.2 134.20 320 12.60 1.3 2.87 200 2900
FQC132-2.2-20 132 5.20 257 10.12 1.35 2.98
FQC128-2.4-20 128 5.04 2.4 146.40 306 12.05 1.5 3.31
FQC128-2.5-20 2.5 152.50 315 12.40
FQC132-2.7-20 132 5.20 2.7 164.70 1.4 3.09
FQC115-3.0-30 115 4.53 3 183.00 454 17.87 2 4.41 300 4350
FQC136-3.0-30 136 5.35 352 13.86
FQC157-6.8-30 157 6.18 6.8 414.80 533 20.98 3.9 8.60
FQC174-9.0-30 174 6.85 9 549.00 570 22.44 5.1 11.24
FQC196-12-30 196 7.72 12 732.00 605 23.82 6.5 14.33
FQC220-20-25 220 8.66 20 1220.00 770 30.31 11 24.25 250 3625
FQC222-20-30 12 26.46 300 4350
FQC352-50-30 352 13.86 50 3050.00 795 31.30 26 57.32
