Digital Dvb-t2 tv Tuner With SDR Function

Digital dvb-t2 tv tuner with SDR function

1,Support DVB-T2,DVB-T,DVB-C VHF /UHF band

2, Watch or Record in original digital quality on your PC

3,Small and Compact size,easy to carry

4,Use Time Shifting to Pause and rewind Live TV

5,Record your favorite shows or schedule future recordings.

DVB-T2 TV220 Supported TV standard

1,DVB-T2,DVB-T,DVB-C VHF /UHF band
2,Stereo/dual channel sound
3,Antenna input:IEC connrctor
4,PC-interface:USB 2.0 (HI-Speed)

DVB-T2 T120 TV recording formats :

1,MPEG-2 transport stream
2,MPEG-4 H.264(AVC)

 DVB-T2 T120 System Requirement:

DVB-T2 T120 Frequency:

DVB-T Frequency:48.25~863.25MHz  tuning  range
 Transmission Mode:2K  FFT or 8K  FFT COFDM demodulator
 Code  Rate:1/2, 2/3, 3/4, 5/6  and  7/8
 Guard  Interval:1/4, 1/8, 1/16, 1/32
 Constellation :QPSK, 16QAM,  64QAM
 Bandwidth:6, 7  or 8  MHz

DVB-T2 Frequency:48.25~863.25MHz tuning  range
 Transmission Mode:1k, 2k, 4k,  8k,  16k,  32k
 Code  Rate:LDPC+ BCH 1/2, 3/5, 2/3, 3/4,  4/5,  5/6
 Guard  Interval:1/4, 19/256, 1/8, 19/128, 1/16, 1/32,1/128
 Constellation :QPSK, 16QAM,  64QAM,  128QAM, 256QAM
 Bandwidth:1.7, 5, 6, 7  or 8  MHz

DVB-C Frequency: 47-862  MHz  tuning  range (DVB-C)
 Transmission Mode:COFDM demodulator
 Code  Rate: 16/32/64/128/256  QAM
(DVB-C :  ITU-T J.83  annex A  and  C)


 DVB-T2 T120 Package Includes:

• DVB-T2/T/C USB Stick
• Antenna
• Installation CD
• Remote Control
•  quick start guide

Pictures
