Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports

Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports thumbnail-1
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports thumbnail-2
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports thumbnail-3
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports thumbnail-4
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports photo-1
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports photo-2
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports photo-3
Best 300Mbps Adsl Modem Router With 1RJ11 Port 4 RJ45 Ports photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Style:
External
Type:
Wireless
Contact Supplier Request Quote Chat Now
Newsky Tech. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Style External
Type Wireless
Interface Type Other, 1 RJ11, 4 RJ45, 1 usb
Transmission Rate Other, DL:24Mbps; UL:1Mbps
Certification CE/ROHS/FCC
Brand Name Newsky/OEM
Model Number T263
Place of Origin Guangdong, China
Product Description

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports

Sales Key

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports

uplink rate up to 1 Mbps and downlink rate up to 24 Mbps
provides one RJ11 telephone interface, four RJ45 Ethernet interfaces, and one USB host 2.0 interface
Support VPN pass-through, including IPSec and multiple parallel PPTP tunnel

Compliant with IEEE802.11b/g/n standards, high access to the Internet wirelessly

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports

System Specifications of 300mbps wifi dongle
Chipset MT7505

Protocols

of 300mbps wifi dongle



  • RFC 2684 Multiprotocol Encapsolution over ATM Adaptation Layer 5
  • RFC 1483 Multiprotocol Encapsolution over ATM Adaptation Layer 5
  • RFC 2516 PPP over Ethernet (PPPoE)
  • RFC 1662 PPP in HDLC- Like Framing
  • RFC 1332 PPP Internet Protocol control Protocol
  • RFC 894 A Standard for the transmission of IP Datagrams over Ethernet Networks
  • RFC 1042 A Standard for the transmission of IP Datagrams over IEEE 802 networks
  • MER (IP over Ethernet over AAL5)
  • PPTP, L2TP, IPSec and SIP application layer gateway (ALG)
  • Self-learning Bridge (IEEE 802.1D Transparent Bridging)
  • Support at least 64 learning MAC addresses
  • RFC 768 User Datagram Protocol (UDP)
  • RFC 791 Internet Protocol (IP)
  • RFC 792 Internet Control Message Protocol (ICMP)
  • RFC 793 Transmission Control Protocol (TCP)
  • RFC 826 An Ethernet Address Resolution Protocol (ARP)
  • RFC 862 Echo Protocol
  • G.992.1 (T1.413)
  • G.992.2 (G.dmt), G.lite
  • G.992.3 (G.bis/ADSL 2)
  • ATM forum UNI3.0, 3.1 and 4.0 permanent virtual circuts (PVCs)
  • CBR, UBR, VBR-rt and VBR-nrt
  • ITU-T i610F4/F5 OAM
  • IP routing

Wireless Features

of 300mbps wifi dongle

 Standard IEEE 802.11 b/g/n
Frequency band
  • 802.11b: ISM band 2.400 GHz - 2.484 GHz (according to the local regulations)
  • 802.11g: ISM band 2.400 GHz - 2.484 GHz (according to the local regulations)
  • 802.11n draft:

           - ISM band

           - 2422 MHz - 2452 MHz  (channel BW = 40 MHz)

           - 2400 MHz - 2483.5 MHz (channel BW = 20 MHz)


 Modulation schemes
  •  802.11g: 64QAM, 16QAM, QPSK, BPSK, DSSS
  •  802.11b: CCK, DQPSK, DBPSK
  •  HT20 and HT40: 64QAM, 16QAM, QPSK, BPSK
 Wireless data rate
  •  802.11b: 11, 5.5, 2, 1 Mbps per channel, auto fallback for extended range
  •  802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps per channel, auto fallback for extended range
  • HT20: up to 150 Mbps
  • HT40: up to 300 Mbps
 Operating Channels
  •  802.11b:

           - 4: France

           - 11: USA and Canada

           - 13: Most European countries

           - 14: Japan

  • 802.11g:

          - 11: USA and Canada

          - 13: Most European countries

          - 14: Japan

  • HT20:

          - 11: USA and Canada

          - 13: Most European countries

          - 14: Japan

  • HT40:

          -3 - 9: USA and Canada

          -3 - 9: Most European countries
 Transmission distance
  •  100m indoors coverage area
  •  300m outdoors coverae area

(varying depending on the actural environment)
 Security  64 bit, 128 bit WEP, AES, TKIP, WPA, WPA2, 802.1x

Basic Features

of 300mbps wifi dongle
  • Set IP address and subnet mask at the LAN end and manage domain name
  • VLAN and Port binding at the LAN end
  • Multi-IP address management at the LAN end
  • DHCP server, Option 60/15/42/50/250, and management of multiple address pools
  • DHCP Relay, compatible with RFC2131, RFC951, RFC1542
  • 10M/100M, self-adaptation, half duplex and full duplex management of the LAN port
  • Up to eight WAN connections
  • static uplink, configuring of static IP address, subnet mask, DNS and gateway
  • PPPoE uplink, configuring of user name, password, MRU, PAP and CHAP authentication, disconnection upon idle overtime
  • DHCP uplink,obtaining the IP address through DHCP
  • Bridge uplink
  • VLAN at the WAN end and 802.1q VLAN
  • NAT and NAPT

Advanced Features

of 300mbps wifi dongle


  • ALG: TFTP/FTP/PPTP/RTSP/L2TP/H323
  • MAC address filtering in the whitelist mode
  • Virtual server (NAPT configuration page), meeting the TR098 requirements for port mapping nodes, supporting 16 entries of virtual server configuration
  • DNS agent
  • Manual configuration of DNS
  • QoS:

          – Interface management, supporting strict-priority (SP) and DWRR scheduling modes

          – Queue management, supporting eight priority queues

          – Flow classification management

  • Anti-DoS, independent switch for each protection item, and anti-port-scanning switch
  • IP filtering, security level configuration, blacklist and whitelist based on WAN/LAN end (each list supporting up to 20 entries of IP filtering configuration)
  • Ping/Web/Telnet/SSH/FTP/TFTP local access control
  • Ping/Web/Telnet/SSH/FTP/TFTP remote access control
  • UPnP
  • IGMP Snooping and IGMP data control of the port
  • IGMP relay
  • Static routing management, supporting up to 16 entries of static routing configuration
  • Dynamic routing management, RIPV1, RIPV2, active and passive modes
  • SNTP
  • URL filtering, blacklist and whitelist filtering, supporting up to 20 URL entries
  • DMZ

Status Enquiry

of 300mbps wifi dongle


  • System information
  • ADSL information
  • Host list at the LAN end
  • WAN connection status and statistics information
  • LAN statistics information

Configuration Management

of 300mbps wifi dongle



  • Web, TR069 and SNMP configuration management
  • Telnet and SSH
  • Restore to the factory defaults and keep key parameters, reboot the router
  • Two-level user management, including administrator and user
  • Ping diagnostics
  • Software version upgrade, double Image backup, and HTTP upgrade
  • Upgrade and download of the configuration file of HTTP and TFTP server
  • Record log, upload log through TFTP, clear log, and download log through HTTP
External Connectors of 300mbps wifi dongle
  • 1 x RJ11 DSL interface
  • 1 x WLAN/WPS button
  • 1 x reset button
  • 4 x RJ45 Ethernet interfaces
  • 1 x USB host 2.0 interface
  • 1 x power interface
  • 1 x power switch
  • 2 PCB antenna

Ethernet Interface Features

of 300mbps wifi dongle


  • Fully compliant with IEEE802.3/802.3u standards
  • 10Base-T and 100Base-TX
  • Half duplex and full duplex
  • Auto MDI/MDIX
  • Flow control
Consumption   10W
Environment Requirement of 300mbps wifi dongle
Operating Temperature of 300mbps wifi dongle     0ºC—40ºC
Storage Temperature of 300mbps wifi dongle -20ºC—70ºC
Operating Humidity of 300mbps wifi dongle 10%—95%, non-condensing
Storage Humidity of 300mbps wifi dongle  5%—95%, non-condensing
Power supply of 300mbps wifi dongle  12 V DC, 1 A
EMC and safety of 300mbps wifi dongle
Regulation Compliance of 300mbps wifi dongle
  • FCC
  • CE
  • CCC Class B
Safety Regulations of 300mbps wifi dongle  UL
Green Standard of 300mbps wifi dongle  ROHS

Pictures

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 portsBest 300Mbps adsl modem router with 1RJ11 port 4 RJ45 portsBest 300Mbps adsl modem router with 1RJ11 port 4 RJ45 portsBest 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports

Best 300Mbps adsl modem router with 1RJ11 port 4 RJ45 ports
