Multilayer Screening Machine Vibrating Sieve for sale
- Qingdao Shanghai or any other China port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Factory Price Sand Circular Vibrating Screen for sale
-
High Capacity Mining Machinery Vibrating Screen Price
-
High Efficiency Linear Vibrating Screen for sale
-
High Performance Durable Sand Vibrating Screen Vibration Classification
-
High Quality Iron Ore Screening Machine
-
High efficiency mining machinery base-type vibrating screen machine vibrator
Product Details
| Condition | New | Type | Circular | |
| Application | Ore | Place of Origin | Shandong, China | |
| Brand Name | Zhaoxin | Model Number | 2YA1842 | |
| Voltage | 380V 50HZ, can be customized | Power(W) | 15KW | |
| Dimension(L*W*H) | 4331x3020x2675mm | Weight | 6437KG | |
| Certification | ISO9001:2008 | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
No packaging or as per customer's requests.
Product Description
Multilayer Screening Machine Vibrating Sieve for sale
Features of vibrating sieve for sale
1. YA series circular vibrating screen adopted the international advanced environmental Ring-Grooved rivet, Frame-type screen box frame structure, eccentric shaft plus eccentric block vibrator, high Gear Transmission system. Low stress damping springs and super heavy large clearance bearings and thin oil lubrication and other advanced techniques and technologies.
2. Posses of screen frame structure with high strength, large clearance bearing operating temperature is low, low running noise, long life, safe production, reliable and easy to maintain.
Technical parameter of vibrating sieve for sale
| Model | Area | Screen surface | Feeding particle | Capacity | Motor power | Dimension L*W*H | Weight | |
| /m2 | obliquity ( °) | Mesh size(mm) | /mm | (t/h) | /KW | /mm | /kg | |
| YA1236 | 4.3 | 20 | 6-50 | ≤200 | 80-240 | 11 | 3757X2364X2456 | 4905 |
| 2YA1236 | 4.3 | 20 | 60-50 | ≤200 | 80-240 | 11 | 3757X2364X2456 | 5311 |
| YAH1848 | 8.6 | 20 | 30-150 | 0-150 | 250-1000 | 15 | 4904x3023x2943 | 7122 |
| 2YAH1848 | 8.6 | 20 | 30-150 | ≤ 400 | 250-1000 | 15 | 4904x3020x2943 | 7740 |
| YA2148 | 10 | 20 | 6-50 | ≤ 210 | 180-630 | 18.5 | 4945x3423x3515 | 9033 |
| 2YA2148 | 10 | 20 | 6-50 | ≤ 210 | 180-630 | 22 | 4945x3463x3515 | 10532 |
| YAH2148 | 10 | 20 | 13-200 | ≤ 400 | 270-1200 | 18.5 | 4945x3423x3501 | 10430 |
| 2YAH2148 | 10 | 20 | 30-150 | ≤ 400 | 270-1200 | 22 | 6092x3423x3501 | 11190 |
| YA2160 | 12.6 | 20 | 3-80 | ≤ 200 | 230-800 | 18.5 | 6092x3463x3674 | 9926 |
| 2YA2160 | 12.6 | 20 | 6-50 | ≤ 200 | 230-800 | 22 | 6116x3619x3849 | 11249 |
| YAH2160 | 12.6 | 20 | 30-150 | ≤ 400 | 350-1500 | 30 | 6116x3619x3849 | 12490 |
| 2YAH2160 | 12.6 | 20 | 30-150 | ≤ 400 | 350-450 | 30 | 6116x3619x3849 | 13858 |
| YA2448 | 11.5 | 20 | 6-50 | ≤ 200 | 200-700 | 18.5 | 4945x3729x3473 | 9834 |
| YAH2448 | 11.5 | 20 | 6-50 | ≤ 400 | 310-1300 | 30 | 4970x3925x3638 | 11830 |
vibrating sieve for sale
Safe shipment of vibrating sieve for sale
Before sales: Guide customer to choose the most suitable type of equipments; provide advanced, energy-saving and practical flow chart as well as responsible for designing the whole schem.
On sales: Inspect the product seriously before out of the factory; Invite customer for commissioning in the spot and delivery according to the contract.
After sales: Company can send technical persons for guiding to install ,debugg and train the workers.
We will provide one-year warranty to make sure your machine work well. We have spare parts of the very machine in stock all the time which means the replacements can be sent to you timely.
Certificate and honor
Shandong Zhaoxin Heavy-duty Mining Machinery Co., Ltd. is a professional manufacturer of all kinds of mining equipment, with ISO9001-2008 certificated.
With 30 years manufacturing experience and scientific management and strong financial strength, the company has become a large and leading manufacturer in mineral processing and smelting equipment for nonferrous metals and nonmetals in Shandong area.
Among processing equipment, there includes feeding, crushing, sieving, grinding, classification, stirring, flotation, magnetic separation and cold separation. Moreover, the company offers full service from mining, prospecting, mineral processing experiment, project technical design, machinery and equipment installing to technical conduction and operators training.
Our workshop
Welcome to visit our factory!
Q: About payment
A:Usually 30%T/T prepaid and 70%TT to be paid upon received copy of bill of lading.
A:Commonly 10~30 days after received 30% deposit. We will advise the detailed delivery time upon received your specific inquiry.
Q:Instalation
A: As per customer's requests, Zhaoxin would arrange installation technicians to supervise and assist in the assembly and commissioning of the equipment.
Q: About warranty
A: The warranty is one year exclude the wearable parts of the machine.
Q: What if customer not familiar with mining?
A: Do not worry, Zhaoxin offers full service from mining, prospecting, mineral processing experiment, project technical design, machinery and equipment installing to technical conduction and operators training.
If any question about our products, please feel free to contact us.
Company Profile
Shandong Zhaoxin Heavy-Duty Mining Machinery Co., Ltd is located at No.66 Jinlong Road, Zhaoyuan Economic & Technological Development Zone which is a national economic development zone in China. With 30 years manufacturing experience and scientific management and strong financial strength, the company has become a large and leading manufacturer in mineral processing and smelting equipment for nonferrous metals and nonmetals in Shandong area. Zhaoxin machinery has exported to more than 20 countries. The company mainly manufactures mineral processing and smelting equipment with daily processing capacity of 50 to 5000 MT and automatic control equipment with 20 varieties and more than 200 items. Among processing equipment, there includes feeding, crushing, sieving, grinding, classification, stirring, floatation, magnetic separation and cold separation. Moreover, the company offers full service from mining, prospecting, mineral processing experiment, project technical design, machinery and equipment installing to technical conduction and operators training. The company has occupied a good reputation in this industry by fist class of quality, reasonable price and durable operation life. The company is ISO9001:2008 certificated. Mr. Luan Wanxin, chairman and general manager of the company, greet all friends from home and abroad. We are sure that our service from heart and soul will make all customers satisfied from head to toe.
