Specifications
Tea bag packing machine1.both inner bag and outer bag
2.inner bag with thread and tag
3.filter paper
puter control
DXDT-10B Tea Bag Packing Machine
Scope of applications:
This machine is used in seeds. Medical, health-care and tea industries for the automatic packing of vegetable seed, Chinese medical pills, healthcare tea and packed tea.
The machine can implement simultaneous packing of inner and outer packing by filling the material into the inner pack first and then putting the inner pack into the outer one.
It can automatically perform pack-making, metering, filling, banding, cutting, counting, thermal pressing of batch number and finished product output.
Technical Parameters:
Model | DXDCH- 10B | |
Bag size | inner bag | (L) 50-60 mm/(W) 30-80mm |
outer bag | (L) 60-120 mm/(W) 70-90 mm | |
Capacity | 20-40bags/min | |
Max Filling range | 12ml | |
Power | 220V,50HZ,3.35KW | |
Weight | 700Kg | |
Dimension(L*W*H) | 1200X850X1900cu.mm3 (L*W*H) | |
Why our machine better than other similar machines?
1. All the cover of the packaging machine is 304 SS including everything screw on the body of the packaging machine to prevent the machine get rusted within the 10 years!
2. The feeding way for this packaging machine is volume cups(six cups) or the weigher, you can choose according to the products of you!
3. The sealing system for this packaging machine is specially designed by our engineer, there are high-temperature bearings within the sealing system, the temperature it can bear is 300 °C,it is suitable for any packaging materials.
4. The digital temperature is equipped with this packaging machine, the setting temperature and the actual temperature will be always the same just because the digital temperature controller.
5. Also one point, the temperature of the roller is measured by the clip ring rather the bearing bush which should be change every month, the clip ring can be used for more than one year and the temperature measured by the clip ring is more accurate than the bearing one.
How to use:
Please see the User Manual to see how to set up and use this machine.
Also after buy the machine, we will send the video show you how to use this machine step by step on request.
After-sale service:
1. One year quality warranty and supply spare parts at low cost for life span after sale.
2. 24 hours/365 days online technical service.
3. Training offered.
Pictures:
