Help CenterTS6802 Fiber Optic Talk Set
Related Products
-
TS6802 Fiber Optic Test Equipment,Optical Fiber Talk SetUS$ 300 - 1,000MOQ: 1 Pair -
TS6802 Fiber Talk SetUS$ 300 - 1,000MOQ: 1 Pair
-
TS6802 Fiber Optic Test Equipment,Optical Talk SetUS$ 300 - 1,000MOQ: 1 Pair
-
TS6806 Optical Fiber Talk SetUS$ 300 - 1,000MOQ: 1 Pair
-
TS6806 Fiber Talk SetUS$ 300 - 1,000MOQ: 1 Pair
Specifications
1. Fiber Optic Talk Set2. Full-duplex digital communication
3 .High quality conversation
4.120km transmission distance
TS6802 series optical talk set adopts full duplex digital communicaiton technology.
TS6802 series optical talk set can realize 2 party talking via a single fiber.
TS6802 series optical talk set has large LCD screen,low backgroud noise,high quality conversation, 120km transmission distance,50 hours standby time.
Besides acting as a fiber optic talk set,TS6802 fiber optic talk set can also work as single wavelength stable
light source.
Features
- Fiber Optic Talk Set
- Two parties communicate via a single fiber
- Full-duplex digital communication
- High quality conversation
- 120km transmission distance
- 20 hours working hours as talk set
- Low background noise
- Low power indication
- Light source function
Specifications
Model |
TS6802 |
Wavelength (nm) |
1310/1550 |
Emitter |
FP-LD |
Optical Connector |
FC/PC |
Transmission Distance (km) |
≥120 |
Dynamic Range (dB) |
>40 |
Output Power |
-5~-7 |
Output Stability (dB,30mins@20°C) |
<=0.1 |
Battery (v) |
Lithium 7.4 |
Operating Time (h) |
20(Talk Set)/50(standby)/100(Light Source) |
Operating Temperature (°C) |
-10 ~ +60 |
Storage Temperature (°C) |
-25 ~ +70 |
Dimension (mm) |
190x100x50 |
Weight (g) |
315 |
Standard Accessories
1) Main Unit
2) Earphone
3) Cleaning Stick
4) Battery
5) Power Adapter
6) Carrying Bag
7) Manual
Ordering Information
TS6802-C-PA
1) C=Connector
C1=standard FC connector
C2= interchangeable FC/SC/ST connector
2) PA=Power Adapter
PA1= USA power adapter
PA2= EU power adapter
1. Standard warranty is 18 months.
2. Extended warranty is available with reasonable and addtional cost.
1. Fiber Optic Talk Set+cleaning stick+earphone+manual+carrying pouch+carton box.
