Specifications
1) Mini fiber meter2) small size and lightweight
3) 6 calibration wavelength
4) FC/SC/ST interchangeable connector
PM6100 series Mini Fiber Meter is a pocket size power meter. It has mini size but strong function.
PM6100 series Mini Fiber Meter has 6-calibration wavelength to test both SM and MM fiber.
With FC/SC/ST and 2.5mm interchangeable connector, it is easy to accommodate multi test port.
With 3pcs alkaline battery, it can continuously work 360 hours.
PM6100 series Mini Power Meter is suitable for installation, operation and maintenance, and a good
choice for your work.
Features
- Mini Fiber Meter
- High Sensitivity and large dynamic range
- Optional FC/SC/ST/ connector
- Lower power indication
- 10 minutes auto-off function
- 360 working hours
Specification
Model | PM6100T | PM6100C |
Wavelength Range (nm) | 800~1700 | |
Detector | InGaAs | |
Connector | FC/SC/ST+2.5mm universal | |
Measurement Range (dBm) | -70~+6 | -50~+26 |
Uncertainty | ±0.25 | |
Calibration Wavelength (nm) | 850/1300/1310/1490/1550/1625 | |
Resolution | 0.05 | |
Battery | AAA (3pcs) | |
Operating Time (h) | 360 | |
Working Temperature (°C) | -10~+50 | |
Storage Temperature (°C) | -20~+70 | |
Auto-off Time (min) | 10 | |
Dimension (mm) | 93x59x16 | |
Weight (g) | 66 | |
Standard Accessories
1) Main Unit
2) Cleaning Stick
3) Battery
4) Carrying Bag
5) Manual
Ordering Information
PM6100 M-D-C-W
| |||
Measurement Range (M) | Detector (D) | Connector (C) | Wavelength (W) |
M1: PM6100T M2: PM6100C
| D1: InGaAs D2: Si D3: Ge | C1:Interchangeable FC/SC/ST C2:Interchangeable FC/SC/ST/LC
| W1:850/1300/1310/1490/1550/1625nm W2: 850/980/1300/1310/1490/1550nm W3: others
|
1. Standard warranty is 18 months.
2. Extended warranty is also available with addtional and reasonable cost.
3.Cutomized products are also avaialbe as per your request.
1. mini fiber meter+cleaning stick+battery+manual+carrying pouch+carton box.
