LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector

LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector thumbnail-1
LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector thumbnail-2
LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector thumbnail-3
LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector photo-1
LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector photo-2
LS6200 Optical Light Source 1310/1550nm FC/SC/ST Connector photo-3
US$ 60 - 100 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Sinomor
Model Number:
LS6200
Contact Supplier Request Quote Chat Now
Hangzhou Sinomor Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Sinomor
Model Number LS6200

Specifications

1) Optical light source
2) Dual wavelength SM or MM
3) FC/SC/ST interchangeable connector

LS6200 Optical Light Source 1310/1550nm FC/SC/ST connector





Overview

LS6200 optical light source is designed to work together with PM6100 series optical power meter.

LS6200 optical light source can provide 1 to 2 wavelengths in one unit from SM to MM.

The output power is stable and performance is good.



Features

  • Optical Light Source
  • High stable output
  • Optional FC/SC/ST connector
  • 10 minutes auto-off function
  • Low power indication

Specification



Model

                           LS6200

 Wavelengths (nm)

1310/1550

850/1300

 Emitter Type

FP-LD

FP-LD or LED

 Output Power (dBm)

-7~-6

-7~-6 or >=17

 Spectral Width (nm)

≤10

 Output Stability (dB)

±0.05@15mins;  ±0.1@8hours

 Optical Connector

FC/SC/ST

 Power Supply

3pcs 1.5V alkaline batteries

 Working Time (hrs)

40

 Operating Temperature (°C)

-10~+60

 Storage Temperature (°C)

-25~+70

 Dimension (mm)

150x74x26

 Weight (g)

200





Standard Accessories

1)   Main Unit

2)   Cleaning Stick

3)   Battery

4)   Carrying Bag

5)   Manual



Ordering Information

LS6200-L-C-W

1)   L=Laser

L1: LD  (for SM)

L2: LED (for MM)



2) C= Connector Type

C1: interchangeable FC/SC/ST/PC

C2: interchangeable FC/SC/ST/APC



3) W=Wavelength

W1: 1310/1550nm

W2: 850/1300nm

W3: Others
