EUS 4000 Repair Test Kits for EUP and EUI

Injectronix Co., Ltd.
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-1
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-2
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-3
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-4
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-5
EUS 4000 Repair Test Kits for EUP and EUI thumbnail-6
EUS 4000 Repair Test Kits for EUP and EUI photo-1
EUS 4000 Repair Test Kits for EUP and EUI photo-2
EUS 4000 Repair Test Kits for EUP and EUI photo-3
EUS 4000 Repair Test Kits for EUP and EUI photo-4
EUS 4000 Repair Test Kits for EUP and EUI photo-5
EUS 4000 Repair Test Kits for EUP and EUI photo-6
US$ 1,000 - 15,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
injectronix
Model Number:
EUS-4000
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
BEIJING TIANJIN SHANGHAI FUJIAN QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name injectronix
Model Number EUS-4000
Warranty 1 Years
EUS-4000 Repair Test Kits for EUP and EUI

EUS-4000's new addition Function of BIP (RT) released

Test an EUI or an EUP on a conventional pump test bench. Offer adapter kits for most EUIs and EUPs on the world market.
The EUS-4000 repair tester is designed to perform repair tests for different type of Electronic Unit Injectors (EUI) and Electronic Unit Pumps (EUP). The tester consists of a mechanical cam box (CB-1000) with customer specified EUI/EUP adapter kits and a modular designed electronic controller (EU-4000).  The CB-1000 cam box is driven by a standard high pressure fuel injection pump test bench. The EU-4000 controller is modular designed to fit customer’s applications for testing various EUI.s/EUPs.

Testing an EUI Testing an EUP
The tester is capable to test EUI/EUP products for following brands of manufacturers.

EUI/EUP Applications

Design Features

  • One cambox for all major EUI/EUP models with corresponding adapters and camshafts
  • Cambox mounting height 125mm (from the center of camshaft to bench mounting platform) for Bosch type pump test bench
  • EU-4000 Controller with its modular design may be tailored to meet various customer application.
  • Customer may upgrade EU-4000 by adding a few more optional modules
  • EU-4000 is able to detect and enable automatically the installed modules in the system
    •  Base system. Single solenoid EUI/EUP module
      • Most of EUI/EUP on the market
      • Cummins CELECT EUI,L10, M11, N14
    • Option. Dual-solenoid module for Delphi E3 EUI
    • Option. Piezo EUI module for VW Piezo EUI
    • Option. Cummins ISX EUI metering and timing control module kits, including
      • Cummins HPI-TP electronic control module to drive 2 kinds of injectors,
        • ISX/QSX/Scania 12L;
        • Kamatzu P1250
      • TP-2000 Hydraulic Module
      •  Adapter for injectors of Cummins ISX and Scania engines
    • New Option. EUI Response time measurement
  • Adjustable Beginning of Injection (BOI), in crank angle degrees
  • Adjustable injection period (PW), in crank angle degrees
  • Engine standard cam lobe design
    • Four levels of cam lifts

    • Constant velocity cam lobe to generate higher injection pressure, 3 times higher than cheap eccentric cams




TP-2000 Modual for Cummins ISX EUI testing

  • New Option. Cummins ISX EUI metering and timing control module kits, including
    • Cummins HPI-TP electronic control module
    • TP-2000 Hydraulic Module

Cotact me directly, we will responce immediately, usually within 12 hours.

Phone/Whatsapp:86-18600253466
Email: liu.ruijing(AT)
Skype: Linda12828

Happy life, happy time every day!

Thanks for visiting our store!
