Home > Computer Products > Industrial Computer & Accessories > Industrial Computer > Intel Haswell Celeron 1.4GHz or 1.6GHz Duo Core CPU Fanless Industrial Mini Box PC NIS-896 Barebone System
Intel Haswell Celeron 1.4GHz or 1.6GHz Duo Core CPU Fanless Industrial Mini Box PC NIS-896 Barebone System
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Embedded Computer
Brand Name:
YACOO
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Intel Atom N2600/2800 Fanless Embedded Computer NIS-928NegotiableMOQ: 1 Piece -
Intel Atom N2800 Fanless Embedded Computer NIS-886NegotiableMOQ: 1 Piece
-
Intel Atom N2600/2800 Fanless Industrial PC NIS-928 Embedded Box PC Barebone SystemNegotiableMOQ: 1 Piece
-
Intel Atom N2600/2800 Fanless Industrial Mini PC NIS-928 Barebone SystemNegotiableMOQ: 1 Piece
-
Intel Atom N2600 Fanless Embedded Box PC Mini PC Industrial PC NIS-886 Barebone SystemNegotiableMOQ: 1 Piece
Products Status
Stock
Type
Embedded Computer
Brand Name
YACOO
Model Number
NIS-896
Place of Origin
Guangdong, China
| Specifications | ||
| Processor | CPU | Intel® Haswell Celeron 2957U 1.4GHz Duo Core CPU |
| CPU Package | Onboard | |
| FSB | ||
| Chipset | Intel® Haswell | |
| BIOS | SPI BIOS | |
| RAM | Architecture | DDR3 MAX 1666 MT/s |
| Capacity | MAX 16GB | |
| Socket | SODIMM | |
| Display | Graphic Controller | Intel® HD4000 Graphic media accelerator |
| Dual LVDS | N/A | |
| DVI | DVI-I port, Max. resolution:4K | |
| HDMI | HDMI 1.4, Max. resolution:4K | |
| DP | DISPLAY PORT++ 1.2, support DP Dangle,Max. Resolution:4K | |
| Multiplex Display | HDMI+DP+DVI Synchronous or asynchronous display | |
| LAN | Controller | LAN 1: Intel®I210 POE GbE |
| LAN 2: Intel®I210 POE GbE | ||
| Audio | Controller | Realtek HD ALC662 audio decoder(Right&left Channel + Mic) |
| Super I/O | Controller | ITE8782, support 4*COM |
| H/W Monitor | Watch Dog Timer | 0-255 sec., provide watch dog routine |
| Thermal | Fanless Aluminum passive heatsink | |
| I/O | USB 3.0 | 2 x USB 3.0 PORT |
| USB 2.0 | 4*USB2.0 / 1.1, Max. support +5V@1A. | |
| Serial Port | Com1 9-line RS232,RS232/485 (Optional),TX/RX signal, support 4000Vsurge protection | |
| Com2-4 3-line RS232,TX/RX signal, support 4000V surge protection | ||
| GPIO | 8bits, support routine, freely define I/O,3.3V@24mA level | |
| Expansion Bus | SMBUS | Inter integration |
| Mini-PCIe | 1* Half-size Mini-PCIe socket, support PCIe & USB devices | |
| 1* Full-size Mini-PCIe socket, support USB 3G/4G communication Module | ||
| UIM Scoket | 3G UIM slot | |
| Storage | SATA | 1* standard 7Pin SATA-III & power port, max. transmission rate:3Gb/s |
| Laptop SATA | 7+15Pin | |
| M-SATA | 1*Half-size m-SATAII scoket, max. transmission rate:3Gb/s | |
| Power | Power Type | DC9-19V extended voltage dynamic input,support reverse power protection, 3 Pin 5.08mm pheonix port |
| Power Consumption | Typical Power: 15W | |
| Indicator | Status Indicator | HDD LED |
| POWER LED | ||
| Environment | Operating Temp. | -20°C ~ 60°C With SSD |
| 0°C ~ 40°C With HDD | ||
| Storage Temp. | -40°C ~ 80°C | |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing | |
| Storage Humidity | 0% ~ 90% relative humidity, non-condensing | |
| Formfactor | Dimensions | 210x136x35mm |
| Weight | ||
| Certificate | FCC, CE, RoHS compliant | |
