Home > Computer Products > Mainboard > Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860

Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860

Shenzhen Yacoo Technology Co., Ltd.
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 thumbnail-1
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 thumbnail-2
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 thumbnail-3
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 photo-1
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 photo-2
Intel Atom N2600 -1.6GHz (Dual Core) PC104 Plus Embedded Motherboard ENC-5860 photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Other
Chipset Manufacturer:
Intel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Other
Chipset Manufacturer Intel
Socket Type Other
Form Factor Other
Memory Type DDR3
Graphics Card Type Integrated
Hard Drive Interface SATA
Brand Name Yacoo
Model Number ENC-5860
ProcessorCPU             Intel® Atom™ N2600 -1.6GHz (Dual Core)
CPU PackageOnboard
FSBDMI x 2 5Gb/s
ChipsetG82NM10
BIOS           System BIOS: SPI BIOS
MemoryTech ArchitectureSingle Channel DDR3 1066 MT/s
CapacityOnboard 2GB DDR3
SocketN/A
DisplayGraphic ControllerIntel® GMA3600 Graphic Media accelerator
Dual LVDSSupport dual channel 24bit output, Max. resolution:1920 x 1200
VGAVGA Pinheader, max. resolution: 1920 x 1200 @ 60Hz
Dual DisplayLVDS + VGA Synchronous or asynchronous display
LANControllerLAN1: Intel® 82583V Gigabit Network
AudioControllerRealtek HD ALC662 audio decoder(right&left channel + Mic)
Super I/OControllerSMSC3114
H/W MonitorWatch Dog Timer0-255 sec., provide watch dog routine
CoolerAluminium fanless heat-sink
TPMControllerN/A
I/OUSB           4*USB2.0 / 1.1 (Compatible), Max. support +5V@1A
Serial Port4* (3 *RS-232, 1*RS-485,support auto data flow control)
ESD protection: Air discharge: ±15kV, Contact discharge: ±8kV
Parallel PortN/A
PS/2N/A
GPIO8 bits GPIO, provide routine, freely define I/O,3.3V@24mA level
Expansion BusPCIPC/104 PLUS socket, Max. support 2*PCI devices
Mini-PCIe1*Mini-PCIe socket, support PCIe & USB devices
SMBUS1
StorageSATA           1*Standard SATAII, Max. transfer rate: 3Gb/s
M-SATA   1* Mini-PCIe M-SATA Scoket, support SANDISK protocal, Max. transfer rate: 3Gb/s
Power SupplyPower TypeAT/ATX mode(optional),DC+12V input, support reverse power protection.
Power ConsumptionTypical Power: 8W
Working EnvironmentOperating Temp.0°C ~ 60°C
Storage Temp.-20°C ~ 80°C
Working Humidity0% ~ 90% relative humidity, non-condensing
Storage Humidity0% ~ 90% relative humidity, non-condensing
FormfactorDimensions115mm x 96mm
Weight0.12kg
Certificate FCC, CE, RoHS
