5# tape making machine for plastic zipper
- 60 Piece / Pieces per Month
- Negotiable
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Condition | New | Production Capacity | 99 | |
| Brand Name | zhiteng | Model Number | HKT-01103(12/20) | |
| Voltage | 220v | Power(W) | 1.5kw | |
| Dimension(L*W*H) | standard export packing | Certification | ccc CE | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Automatic zipper machine1. automatic lubrication device
2. automatic stop system
3. Produce 12 tapes at the same time
Quick Details
Place of Origin: | guangdong China (Mainland) | Brand Name: | HKT
| Model Number: | HKT 12/20 |
type: | Automatic zipper machine | product: | all kinds of zipper belts | product range: | metal,plasticand nylon zipper belt |
heads: | 12 | reed width: | 20mm | motor power: | 1.5HP |
output: | 12M/Min | system: | automatic lubrication and automatic stop system | warranty: | 1 year |
after service: | provide spare parts and technical supports |
|
|
|
|
Specifications
Automatic zipper machine
1. automatic lubrication device
2. automatic stop system
3. Produce 12 tapes at the same time
Automatic zipper machine
1. Cam oil auto circulation and lubrication device
2. Yarn automatic braking system with indication light
3. Produce many tapes at the same time.
Applicable scope:
this machine is specially used in producing elastic and unelastic zipper belts for many kinds of zippers, including metal zipper belt, plastic zipper belt, nylon zipper belt and other any kinds of zipper belts.
Features:
1. Special-type machine for producing many kinds of zipper belts, such as metal, resin and nylon zipper belts.
2. Adopt automatically stop device, once the yarn break, the machine will stop automatically.
3. Adopt automatic lubrication device, the oil can cycle and lubricate the machine automatically.
4. Auto regulate device for zipper belt, easy for operator to check the finished belts.
5. Simple structure, stable, low-noise, easy to maintain and repair, long operating life, spare parts available.
Details
HKT Series specification
Model | HKT 8/25 | HKT 12/20 | HKT-D 12/20 (double heads) |
Number of tapes | 8 | 12 | 12*2=24 |
Max tape width (mm) | 24 | 20 | 20 |
Motor power | 1.5 HP | 1.5 HP | 1.5 HP |
Speed | 1400-1600 PRM | 1400-1600 PRM | 1400-1600 PRM |
Heald frame | 12 pcs | 12 pcs | 12 pcs |
Link chain repeat | 8 | 8 | 8 |
Weft density | 3.5-36.7 weft/cm | 3.5-36.7 weft/cm | 3.5-36.7 weft/cm |
Normal attachment | Back take-off device, creel places, normal attachment. | ||
Optional attachment | Beam | ||
