Product Details
Place of Origin: | Zhejiang, China | Brand Name: | OEM | Model Number: | 3.2v 10ah |
Type: | Li-Ion | Nominal Voltage: | Other, 3.2v | Size: | Other, 38*122mm |
Nominal Capacity: | 38120s, 10000mAh |
Product Description
headway 38120s 10ah 3.2v lifepo4 battery cells headway 38120s 10ah 3.2v lifepo4 battery cells
Product Description:
38120S--lifepo4--3.2v--10ah
NO. | ITEM | Specifications | |
1 | Nominal Capacity: | 10000mAh | |
2 | Rated voltage | 3.2V | |
3 | Energy density (Wh/kg) | 105 | |
4 | Internal Resistance | ≤4mΩ | |
5 | Charge (CC-CV) | Charged with constant current to 3.65v and then charged with constant voltage to 0.1-0.2A | |
6 | Charge (float) | ≤3.6V | |
7 | Max. charging current | 3C(30A) | |
8 | Standard. charging voltage | 3.65±0.05V | |
9 | Recommended charging current | 0.5C,5A ×2hours | |
10 | Max. continuous discharging current | 3C (30A)-10C(100A) | |
11 | Max.pulse discharging current(30seconds) | 15C(150A) | |
12 | Recommended discharging current | 1C(10A) | |
13 | Max. End-off discharged voltage | 2.0V | |
14 | Self discharge rate (monthly) | 2-3% | |
15 | Dimensions (mm) | Diameter | 38mm±1mm |
Height | 132mm±1mm | ||
16 | Weight (Approx.) | 330g | |
17 | Working temperature | Charging | 0~45℃ |
Discharging | -20~65℃ | ||
18 | Storage | In one month | -20~45℃ |
temperature | In six months | -20~35℃ |
Features:
1. Good cell consistency, high Max. charge/discarge pulse current.
2. Low internal resistance, low thermal generated and high safety performance.
3. Good high temperature performance.
4. High capacity, low self-discharge rate and long cycle life.
5. Dimension and type(capacity type and ratio type) can be customized.
Applications:
1. EV: pure electric car, pure electric bus, hybrid electric vehicles, hybrid electric bus, recreational vehicles, chill cars.
2. Storage: solar and wind complementary stored energy streetlights, energy storage systems, household energy storage.
3. Power Supply: communication base station power supply, utility power supply, communication industry, emergency power supply and other system standby power etc.
Why choose LifeP04?
1) High power: Higher charge and discharge rate for better performance and efficiency.
2) High energy density
3) Excellent safety: Superior abuse tolerance
4) Extended cycle life: Long battery life in both deep and shallow cycling.
5) No memory effect:
6) Low self-discharge rate: less that 5% per month
7) Wide working temperature range: -20°C--60°C
8) Light weight: lighter 1/3 than the lead-acid batteries
9) Environmental friendly
The advantages of lifepo4 batteries
Widely used in EVs including electric bikes, electric scooters, electric cars / hybrid electric cars,
UPS batteries,
storage batteries for solar power systems,
starter batteries for cars & motorbikes etc.
Product Photos:
Company Workshop:
Certificate:
