Sanitary liquid water oil tank float ball level gauge price
magnetic float tank level gauge
It can be used to measure level of various vessels in the shape of tower, kettle, groove and ball as well as boiler furnace. It can be used in complex conditions, such as highsealing, leak prevention, high pressure, high temperature and corrosion. In the measurement process, no measurement blind area. It strikingly displays the level and has a wide measurement range. Compared with traditional glass plate level gauge, it is safer, more reliable, more advanced and more practical. The most obvious characteristic is the complete isolation of liquid medium and indicator so it can be used safely, reliably and durably in any case.
Feature:
The shell of the turn column uses the polyester and high temperature ceramic, which doesn’t fade and resists high temperature.
It can measure level and interface of liquid in the vessels. Besides on-site instruction, it can be with remote diaphragm, alarm switch, control switch.
It indicates obviously and highlighting. The direction of the observing indication can change angles based on the user’s need.
Wide measuring range, measure a variety of the height of the vessels.
The instruction and the medium are isolated completely, so it is reliable and safe.
Easy structure, convenient installation and the low cost of maintenance.
corrosion-proof, no need power supply and explosion-proof.
The magnet of the turn column adopts permanent magnet materials can run reliably during a long time.
Technical parameter:
| Measurement range | 300-15000mm |
| Accuracy | ±10mm |
| Column diameter | 9mm |
| Operating pressure | ≤10.0Mpa (>10.0Mpa customized); anti-corrosion type ≤1.0Mpa |
| Medium density | ≥0.45g/cm3 |
| Medium density difference | ≥0.15g/cm3 |
| Medium viscosity | ≤0.4Pa·S |
| Equipment vibration | frequency≤25Hz, amplitude≤0.5mm |
| Follow speed | ≤0.08m/s |
| Connection flange | DN20, PN0.6 |
