sparkling water filling machine
- 20 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Condition | New | Application | Other, drinking water | |
| Packaging Type | Bottles | Packaging Material | Plastic | |
| Automatic Grade | Automatic | Driven Type | Mechanical | |
| Power | 5.5KW | Place of Origin | Jiangsu, China | |
| Brand Name | JINRI | Model Number | CGF32-32-10 |
Product Description
Specifications
sparkling water filling machine1.rinsing,filling and capping 3-in-1
2.:50-90mm(D),150-320mm(H)
3.:12000-15000bph(500ml)
CGF32-32-10 full-auto 3-in-1 sparkling water filling machine
Model: CGF32-32-10
Capacity: 12000bph-15000bph(500ml)
Washing head: 32
Filling head: 32
Sealing head: 10
Total power: 5.5KW
Conveying method: Wind delivery, bottleneck suspended operation, filled bottle conveying. (Krones technology)
Washing method: Infibulating the bottleneck washing.( Krones technology)
Filling method: Micro-pressure filling. (Krones technology)
Sealing method: Magnetic screw cap sealing. (Krones technology)
Wine tank shape: SS 316 Ring wine tank(Wall thickness:12mm, cover board thickness: 20mm, motherboard thickness: 25mm)
Transducer: Mitsubishi.(Japan)
Main electrical appliance: Siemens , SuZhou company
Touch screen: TOUCHWIN.(Canada)
Proximity switch: AUTONICS.(Korea)
Optical switch: AUTONICS.(Korea)
Speed reduce: TianYu.(Hangzhou, China)
Frequency motor: Anhui WanNan
Pneumatic component: AIRTAC.(Taiwan)
Dimension: 3050×2250×2800 (L*W*H)
Weight: 4800Kg
