Wholesale high temperature resistant small bellows
Some data of bellows
| DN | ID/OD size | Thickness | Material | Pipe ripple |
| 12mm | ID12 x OD16mm ±0.2 | 0.22 /0.25 / 0.30mm ±0.2 | SUS304/316L | Annular wave |
| 16mm | ID16 x OD20mm ±0.2 | 0.22 /0.25 / 0.30mm ±0.2 | SUS304/316L | Annular wave |
| 20mm | ID20 x OD25mm ±0.3 | 0.22 /0.25 / 0.30mm ±0.2 | SUS304/316L | Annular wave |
| 25mm | ID25 x OD32mm ±0.4 | 0.22 /0.25 / 0.30mm ±0.2 | SUS304/316L | Annular wave |
| 32mm | ID32 x OD42mm ±0.4 | 0.22 /0.25 / 0.30mm ±0.2 | SUS304/316L | Annular wave |
Stainless steel bellows features:
1. The good construction: thin-walled stainless steel corrugated hose hose, the overall weight, greatly reducing the load of construction work and construction time.
2. Corrosion resistance: the body of the bellows 304 or 316L stainless steel is formed at both ends of stainless steel or carbon steel fittings joints with good corrosion resistance. Ensure the seal.
3. The high voltage: taking into account various factors bellows actual operating pressure, the environment and use conditions, all the parameters have been a careful calculation and repeated tests, to ensure its safety under pressure at work.
4. Many kinds: conventional bellows diameter range: DN8-DN4000, other customized according to customer requirements.
5. shockproof, anti-dislocation: stainless steel corrugated hose has good flexibility and compensation displacement characteristics.
6. beautiful appearance: the appearance of clear light, permanent bright as new.
