Specifications
Drying systemMaterial:SUS304
Drying machine is mainly applied in drying bottles or packages in transferring production lines of dairy products, fruit juice, jellies, puddings, beverages, beer, foods and medicines after filling or packing. Generally, it is applied in the latter procedure after spraying sterilization cooling tunnel or water bath sterilization cooling tunnel, to dry packages, and the procedure before marking, pasting, code-spraying and film packing etc.
Product detail
Characteristics of performance:
1. The frame of equipment is made of stainless steel, with compact total structure, nice and clean appearance;
2. Stainless steel meshes chain, being super strong and with great rate of opening and transferring capacity;
3. Spindle-rotating blower of little noise and high-performance centrifugal blower combined for better drying effect;
4. Self-tightening structure makes it convenient to install and adjust;
5. Cool/hot wind modes are available to choose according to various technical requirements of products;
6. Mechanical variable speed or variable frequency speed regulation, and the drying time are adjustable according to technical requirements on production and yield.
Item |
Unit |
CGJ140-125-2 |
CGJ20-60-2 |
CGJ40-60-2 |
|
Characteristics of performance Packing form materials specification |
ml |
Plastic package yoghurt 125*80*15-125ml |
Ps compound package jelly puddings 110*63*15-60ml |
Plastic cup jelly 80ml |
Handling capacity |
package/hour |
40000 |
20000 |
40000 |
Handling time |
Sec. |
120 |
120 |
120 |
Dimension |
mm |
6100*2660*1430 |
2100*2000*1550 |
4300*2200*550 |
Motor power |
kw |
25.25 |
7.25 |
21.5 |
Unit |
CGJ140-125-2 |
CGJ20-60-2 |
CGJ40-60-2 |
|
|
Characteristics of performance Packing form materials specification |
ml |
Plastic package yoghurt 125*80*15-125ml |
PsPs compound package jelly puddings 110*63*15-60ml |
Plastic cup jelly 80ml |
/Handling capacity |
package/hour |
40000 |
20000 |
40000 |
Handling time |
Sec. |
120 |
120 |
120 |
Dimension |
mm |
6100*2660*1430 |
2100*2000*1550 |
4300*2200*550 |
Motor power |
kw |
25.25 |
7.25 |
21.5 |
