Specifications:
Characteristic of 5 Gallon Barreled Water Filling Production Line:
1. This 5 gallon barrel filling machine integrates with rinsing, filling, and capping function.
2. Its body unit is made of stainless steel featuring anti-corrosive property and easy cleaning.
3. The rinsing nozzles make use of American spraying system technology and they can be used for fresh water rinsing and disinfectant cleaning application. The disinfectant can be recycled.
4. The main components of this device are all selected from international famous suppliers.
5. Designed with compact structure, high efficiency, and stable operation, our product is highly automatic equipment which combines electric control system with pneumatic control system.
Parameter
| Model | QGF-150 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 | QGF-2000 |
| Filling heads | 1 | 2 | 3 | 4 | 6 | 8 | 16 |
| Barrel volume (L) | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 | 18.9 |
| Barrel size (mm) | Ø 270×Ø 490 | Ø 270×Ø 490 | Ø 270×Ø 490 | Ø 270×Ø 490 | Ø 270×Ø 490 | Ø 270×Ø 490 | Ø 270×Ø 490 |
| Production capacity (bph) | 150 | 300 | 450 | 600 | 900 | 1200 | 2000 |
| Air pressure (Mpa) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.6 | 0.6 |
| Air consumption (m³/min) | 0.3 | 0.4 | 0.5 | 0.5 | 0.8 | 1.2 | 1.2 |
| Power (kw) | 3.8 | 6.5 | 7.5 | 7.5 | 10 | 14 | 15 |
| Dimension (L×W×H)(m) | 4.7×1.4×1.7 | 5.1×2.5×2.2 | 6.6×3.5×2.2 | 6.6×4.5×2.2 | 6.6×5.0×2.2 | 2.8×2.4×2.7 | 2.9×3.5×2.7 |
| Weight (kg) | 1000 | 1750 | 2200 | 2500 | 2800 | 3100 | 4000 |
---Product Images
WELCOME TO JINRI BEVERAG MACHINERY!
---Factory
---Certification
---Working
---Customers
---Delivery
For any further information about this machine,please contact us without hesitation,we will reply to you asap.Thank you and welcome to JINRI .
