Help CenterFully Automatic Waste EPE Plastic Scrap Recycling Machine Pelletizer Granules Extrusion Line
Related Products
-
Double Extruder Plastic Bag Film Scrap Recycling Granules Making Line Pelletizing MachineUS$ 2,800 - 54,000MOQ: 1 Set -
Plastic Film Bag Scrap Recycling Pelletizer Machine PE Extruder Granules Line AutomaticUS$ 2,800 - 54,000MOQ: 1 Set
-
Granules Making Machine Granulator Plastics Equipment With Hydraulic Screen Change Recycling for BottleUS$ 2,800 - 54,000MOQ: 1 Set
-
Single Screw Plastic Film Scrap Recycling Extruder Granules Line Pelletizer MachineUS$ 2,800 - 54,000MOQ: 1 Set
-
Double Stage Plastic Film Scrap Recycling Extruder Granules Line Pelletizer MachineUS$ 2,800 - 54,000MOQ: 1 Set
Inquiry Tips for Customer:
1) What is your Material of recycling products?
2) What is your required Output?
Product Brief:
Plastic granulator, life is more than five times the ordinary granulator screw imported high-quality carbon structural steel, carburizing heat treatment production process, bearings, advanced lubrication, abrasion resistance, less wearing parts, reasonable structure , solid, easy operation and maintenance. Automatic feeding, crushing, washing, melting, drawing, cooling, pelletizing, automatic temperature control, wet and dry, coarse material, fine material dual-use, screen changer fast, energy efficient, drastically reduce energy consumption, easy to process a variety of waste. 20-280 tons of equipment per month complete specifications, high technical content, stable performance, price concessions in the same industry-leading position.
Product Feature:
1, All the recovered material sorted and broken washing without drying or drying, dried, can be produced, wet or dry.
2, From raw material crushing, washing, the particles are fed into automation.
3, Take full advantage of the high-pressure continuous friction heating system, automatic heating production, to avoid the continuous heating, energy saving.
4, Using split automatic distribution system to ensure the normal operation of the motor safety.
5, Screw and cylinder are made of imported high-strength high-quality carbon structural steel, durable.
Main Specification:
Single Screw Auto Loading Plastic Pelletizing Recycling Machine | ||||
Model |
MS-90 |
MS-100 |
MS-110 |
MS-120 |
Diameter of screw |
Φ90mm |
Φ100mm |
Φ110mm |
Φ120mm |
L/D |
20:1-22:1(L/D) |
20:1-22:1(L/D) |
20:1-22:1(L/D) |
20:1-22:1(L/D) |
Rotation speed of Screw |
10-100r/min |
10-100r/min |
10-100r/min |
10-100r/min |
Main motor power |
22kw |
30kw |
37kw |
45kw |
Output |
68kg/h |
95kg/h |
120kg/h |
135kg/h |
Machine weight |
2600kg |
2800kg |
3000kg |
3200kg |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Single Screw Dry & Wet Dual Usage Plastic Pelletizing Recycling Machine | ||||
Model |
MS-105 |
MS-125 |
MS-135 |
MS-150 |
Diameter of screw |
Φ105mm |
Φ125mm |
Φ135mm |
Φ150mm |
Main motor power |
15kw |
18.5-22kw |
22kw |
25-30kw |
Output |
50-80kg/h |
70-100kg/h |
100-130kg/h |
140-200kg/h |
Machine weight |
800kg |
1200kg |
1400kg |
2200kg |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Single Screw Water Ring Plastic Pelletizing Recycling Machine | ||||||
Model |
MS-110 |
MS-120 |
MS-130 |
MS-140 |
MS-150 |
MS-160 |
Diameter of screw |
Φ110mm |
Φ120mm |
Φ130mm |
Φ140mm |
Φ150mm |
Φ160mm |
Main motor power |
22kw |
30kw |
37kw |
45kw |
70kw |
90kw |
Output |
100-200kg/h |
200-250kg/h |
200-300kg/h |
250-350kg/h |
300-400kg/h |
400-500kg/h |
Pelletizing |
Pull strip pelletizing type water ring pelletizing |
|||||
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Double Stage Plastic Pelletizing Recycling Machine | ||||
Model |
MS-115 |
MS-125 |
MS-135 |
MS-150 |
Main extruder screw Dia. |
Φ115mm |
Φ125mm |
Φ135mm |
Φ150mm |
Auxiliary extruder screw Dia. |
Φ105mm |
Φ105mm |
Φ105mm |
Φ105mm |
Main driver motor power |
18.5-22kw |
18.5-22kw |
22-30kw |
22-30kw |
Auxiliary driver motor power |
5.5-7.5kw |
5.5-7.5kw |
5.5-7.5kw |
5.5-7.5kw |
Output |
80-120kg/h |
100-140kg/h |
120-170kg/h |
150-220kg/h |
Machine weight |
1700kg |
1800kg |
2000kg |
2500kg |
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
EPS EPE PP PS Foam Plastic Pelletizing Recycling Machine | ||||
Model |
MS-200 |
MS-A240 |
MS-B240 |
MS-320 |
Diameter of screw |
Φ200mm |
Φ240mm |
Φ240mm |
Φ320mm |
Main motor power |
22kw |
30kw |
30-11kw |
45kw |
Pelletizing power |
1.1kw |
1.1kw |
2.2kw |
2.2kw |
Output |
70-125kg/h |
150-175kg/h |
150-250kg/h |
200-300kg/h |
Machine weight |
1200kg |
1500kg |
2500kg |
3200kg |
Main Configuration:
*Some configuration can be replaced according to requirement.
Machine Details:
Parts Details:
Plastic Recycling Line:
