Specifications
printing machine1.Easy operation,flexible starting,accurate color register.Model of Machine.
printing machine
Application:Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene,polyproplene bag,cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for good, supermarket handbag, vest bag and clothes bag,etc.
Performance and Characteriestics
1.Easy operation,flexible starting,accurate color register.
2.the meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3.Pneumatic printing cylinder lift and lower, is will stir the printing ink automatically after lifting .
4.the priting ink is spread by the anilox cylinder with even ink color.
5.Reliable drying system coordinated with high-speed rotation, it will automatically break circuit wehn the machine stops.
6.360°continuous and adjustable longitudinal register device.
7.The frequency control of motor speed adapts to different printing speeds.
8.There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
Main Technical Variables
Model of Machine
YT-6600
YT-6800
YT-61000
Max.Width of Printing Material
600mm
800mm
1000mm
Max.Printing With
560mm
760mm
960mm
Length Range of Printed Product
191-914mm
191-914mm
191-914mm
Max.Diameter of Roll Material
φ450mm
φ450mm
φ450mm
Printing Speed
5~80m/min
5~80m/min
5~80m/min
Thickness of plate(Including Two-sides Glue Paper)
2.38mm
2.38mm
2.38mm
