Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > CE Approved Big Power 550kw China Engine With Brushless Alternator Generator 687kva
CE Approved Big Power 550kw China Engine With Brushless Alternator Generator 687kva
US$ 35,999 - 36,599
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Shangchai
Model Number:
GF-550
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Rpm Generator Cheap Brushless Electric Diesel Generator by Shangchai EngineUS$ 12,500 - 13,500MOQ: 1 Set -
Brushless 100% Copper Powerful 200kw 250kva Genset Generator Price List by Shanghai EngineUS$ 11,999 - 12,500MOQ: 1 Set
-
Global Service Low Price Open Type Electric Start Diesel Generator Cetificated by ISO9001US$ 14,999 - 15,200MOQ: 1 Set
-
Chinese Brand Shangchai Cheap Powerful Genset 400kw 500kva CE Approved 3 PhaseUS$ 22,000 - 22,600MOQ: 1 Set
-
Shangchai 50HZ 1500 Low Rpm Generator Diesel for Sale Water Cooled With 6 CylinderUS$ 13,900 - 14,400MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
Shangchai
Model Number
GF-550
Output Type
AC Three Phase
Speed
1500rmp
Frequency
50/60HZ
Rated Power
550kw/687.5kva
Rated Voltage
400V/230V Adjustable
Rated Current
990A
CE approved big power 550kw China engine with brushless alternator generator 687kva
| Genset Information | |||
| Model | GF-550 | Net dimensions (mm) | 4300*1550*2200mm |
| Prime Output(kw/kva) | 550kw/687.5kva | Rated current(A) | 990A |
| Gross weight (kg) | 6100kg | Net weight (kg) | 5900kg |
| Rated voltage(V) | 400V/230V | Noise (dB) | 100dB(A) |
| Fuel Comsuption (g/kwh) | 207g/kwh | Frequency (HZ) | 50HZ/60HZ |
| Steady voltage adjusting rate | ≤±1% | ||
| Transient voltage regulation | +20~--15 % | ||
| Voltage settling time | ≤1s | ||
| Steady State rate adjustment frequency | ≤±1% | ||
| Frequency fluctuation rate | ≤±0.5% | ||
| Transient frequency regulation | +10~-7% | ||
| Frequency recovery time | ≤3s | ||
| Generator configurations | |||
| Engine Brand: | Shangchai | Fuel Injection | Direct Injection |
| Engine Model: | SC27G830D2 | Bore (mm) | 135*155mm |
| Intake System | Turbo charging | Cylinder No. | 12/V |
| Cooling method | Closed circulating water cooling | Speed | 1500rpm |
| Compression Ratio | 16.4:1 | Governor | 110% |
| Starting mode | DC24V electrical starting | Speed adjustment mode | Electronic speed control |
| Alternator configurations | |||
| Alternator Brand: | Fengfengsheng | Protection Grade | IP22 |
| Alternartor Model: | TFW-550 | Connect method | Three phase four wire type y connection |
| Rated output (kw/kva) | 550kw/687.5kva | Excitation method | AVR(Automatic voltage regulator) |
| Rated voltage(V) | 400V/230V | Frequency (HZ) | 50HZ/60HZ |
| Insulation Grade | H Class | Power Factor | COS=0.8 |
