Specifications

S12708

S12712

Switching Capacity

12.32/27.04 Tbit/s

17.44/37.28 Tbit/s

Packet Forwarding Rate

6,240/9,120 Mpps

9,120/12,960 Mpps

MPU Slots

2

2

SFU Slots

4

4

Service Card Slots

8

12

CSS2

1+N MPU backup in a cluster

Up to 1.92 Tbit/s cluster bandwidth, 4 us inter-chassis transmission latency

Wireless Network Management

Native AC

AP access control, AP region management, and AP profile management

Radio profile management, unified static configuration, and centralized dynamic management

Basic WLAN services, QoS, security, and user management

User Management

Unified user management

802.1x, MAC, and Portal authentication

Charging based on traffic volume and online duration

User authorization based on user groups, domains, and time ranges

iPCA

Adds marks on service packets in order to measure the number of lost packets and packet loss ratios in real time with zero payload

Measures the number of lost packets and packet loss ratios at the network and device levels on Layer 2 and Layer 3 networks

SVF

Up to 4K clients (access switches and APs) virtualized into a single device

2-level AS structure

Unified management on Huawei and non-Huawei devices
