Huawei Wifi Access Equipment AP6310SN-GN-CN AP6010SN-GN AP6010SN-GN-CN

Introduction

The AP6610DN-AGN is an enhanced series dual-frequency Access Point (AP).With a high level of physical protection, it is applicable to pedestrian areas, factories, and other challenging environments, meeting the outdoor network deployment requirements.

The AP is applicable to open outdoor areas with high user densities, such as squares, residential communities, schools, and gardens, or outdoor places that have high demands for wireless access, such as pedestrian malls. This AP can be used together with outdoor antenna to provide long-distance network coverage and implements stable radio backhaul in a wireless distribution system.

The AP6610DN-AGN can work as a Fat AP or Fit AP and switch flexibly between the two working modes based on the network plan.

When the wireless network scale is small, customers need to purchase only AP products and set the APs to work as Fat APs. As the network scale expands, tens of or hundreds of APs exist on the network. To simplify network management, customers are advised to purchase ACs to perform centralized management on the APs and set the APs to work as Fit APs.

Specifications

Radio Parameters

Item	Description
Antenna type	Dual-polarization antenna or common outdoor antenna
Maximum number of concurrent users	128
Maximum transmit power	2.4G: 27dBm 5G: 24dBm You can adjust the transmit power from the maximum transmit power by 20 dB, with a step of 1 dB.  NOTE:Actual transmit power depends on local laws and regulations.
Maximum  number of  non-overlapping  channels	2.4 GHz 802.11b/g 20MHz: 3 802.11n 20MHz: 3 40MHz: 1		5 GHz 802.11a 20MHz: 24 802.11n 20MHz: 24 40MHz: 11
	NOTE:The number of non-overlapping channels allowed varies in different countries. For details, see the Country codes & Channels compliance status
Channel Rate	802.11b: 1, 2, 5.5, and 11 Mbit/s
	802.11g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s
	802.11n data rate (2.4 GHz and 5 GHz)
	GI2=800ns		GI=400ns

WLAN features

• Compliance with IEEE 802.11a/b/g/n, providing a maximum rate of 300 Mbit/s
• Maximum ratio combining (MRC)
• Maximum-likelihood detection (MLD)
• Data unit aggregation, including A-MPDU (Tx/Rx) and A-MSDU (Rx only)
• Short GI in 20 MHz and 40 MHz modes
• Priority mapping and packet scheduling based on a Wi-Fi Multimedia (WMM) profile to implement priority-based data processing and forwarding
• Automatic and manual rate adjustment (the rate is adjusted automatically by default)
• WLAN channel management and channel rate adjustment
• Automatic channel scanning and interference avoidance
• Service set identifier (SSID) hiding
• Signal sustain technology (SST)
• Unscheduled automatic power save delivery (U-APSD)
• Control and Provisioning of Wireless Access Points (CAPWAP) in Fit AP mode
• Automatic login in Fit AP mode
• Wireless distribution system (WDS) in Fit AP mode
• Mesh networking in Fit AP mode

Network features
