Specifications
Coffee machine solenoid vibration pumpCoffee Machine solenoid vibration pump
. Main applications:
1. Coffee machine; 2.Water heaters system; 3. The circulation for personal care products, water cycle;
4. Other food-grade appliances.
. Characteristics:
1. Temperature 100 °C (medium) 2, Interference, harassment signal
. Function:
1. PWM speed control 2. FG signal 3. Overvoltage protection
. Power supply:
1. Battery; 2. Power modules
Model |
Rated voltage |
Electric current |
Max. flow |
Power |
Max. Head |
Life |
Noise |
Waterproof class |
Insulation class |
V |
A |
L/H |
W |
M |
H |
dB |
|||
P3530A |
12 |
0.4 |
120 |
4.8 |
2.1 |
20000 |
35 |
May require diving |
A |
P3530B |
24 |
0.2 |
120 |
4.8 |
2.1 |
20000 |
35 |
May require diving |
A |
Note: The above Current, flow, power are under the terms of rated voltage, also the head is "0" m. | |||||||||
When the pumps are installed in the system, the more head and resistance, the less flow and power. | |||||||||
Our food-grade pumps are all through the food-grade certification, specific parameters can also be customized according to customers’ needs!
1;Life: Approximately 20,000 hours under normal conditions (room temperature, ambient conditions)
2;Low noise ≤ 35dba ,1 m distance.
3; Working Performance: Continuous 24-hour work
4;Working temperature: -30°C ~ 100°C
5;Its waterproof performance is very good, you can work not only in water, but also on land.
6.It is food-grade product,which made of high temperature resistant material,can be a long uninterrupted work in hot water, can work continuously 24 hours.
It mainly used in coffee pot, tea, juice machines, drinking fountains and other food-grade appliances, health care and other products.
If you want,pls send the specific requirements what you need,then we will give you the best offer.
Thanks and best regards
Miss Wei Lifang
