Specifications
Sifting and filtering in acid and alkali conditions.Sifting and filtering in acid and alkali conditions. Slurry net in petroleum, sifting and screening mesh in chemical and chemical fiber industry, acid washing mesh in electric plating industry.
Roll Width: 36", 40", 48", 60"
Roll Length: 25Ft, 50Ft and 100Ft
Stainless Steel Wire Mesh Standard Grade made from plain weave or twill weave, materials are available in ANSI304 ANSI316 also other stainless steel 300 series and 400 series.
Specification list of Stainless Steel Wire Mesh / Woven Wire Cloth | |||||
Meshes Per Linear Inch |
Diameter of Wire |
Width of Opening |
Open |
||
Inches |
mm |
Inches |
mm |
||
| 1"
|
0.135 | 3.5 | 0.865 | 21.97 | 74.8 |
3/4" |
0.120 |
3.0 |
0.630 |
16.00 |
70.5 |
3/4" |
0.080 |
2.0 |
0.670 |
17.01 |
79.8 |
2 x 2 |
0.120 |
3.0 |
0.380 |
9.65 |
57.8 |
2 x 2 |
0.105 |
2.5 |
0.395 |
10.03 |
62.4 |
2 x 2 |
0.080 |
2.0 |
0.420 |
10.66 |
70.6 |
2 x 2 |
0.063 |
1.6 |
0.437 |
11.10 |
76.4 |
2 x 2 |
0.047 |
1.2 |
0.453 |
11.50 |
82.1 |
3 x 3 |
0.080 |
2.0 |
0.253 |
6.42 |
57.6 |
3 x 3 |
0.063 |
1.6 |
0.270 |
6.85 |
65.6 |
3 x 3 |
0.047 |
1.2 |
0.286 |
7.26 |
73.6 |
4 x 4 |
0.080 |
2.0 |
0.170 |
4.31 |
46.2 |
4 x 4 |
0.063 |
1.6 |
0.187 |
4.75 |
56.0 |
4 x 4 |
0.047 |
1.2 |
0.203 |
5.15 |
65.9 |
5 x 5 |
0.047 |
1.2 |
0.153 |
3.88 |
58.5 |
5 x 5 |
0.041 |
1.0 |
0.159 |
4.01 |
63.2 |
6 x 6 |
0.063 |
1.6 |
0.104 |
2.64 |
38.9 |
6 x 6 |
0.047 |
1.2 |
0.120 |
3.04 |
51.8 |
6 x 6 |
0.035 |
0.9 |
0.132 |
3.35 |
62.7 |
8 x 8 |
0.063 |
1.6 |
0.062 |
1.57 |
24.6 |
8 x 8 |
0.047 |
1.2 |
0.078 |
1.98 |
38.9 |
8 x 8 |
0.035 |
0.9 |
0.090 |
2.28 |
51.8 |
8 x 8 |
0.032 |
0.8 |
0.093 |
2.36 |
55.4 |
8 x 8 |
0.028 |
0.7 |
0.097 |
2.46 |
60.2 |
10 x 10 |
0.047 |
1.2 |
0.053 |
1.34 |
28.1 |
10 x 10 |
0.035 |
0.9 |
0.065 |
1.65 |
42.3 |
10 x 10 |
0.032 |
0.8 |
0.068 |
1.27 |
46.2 |
10 x 10 |
0.025 |
0.63 |
0.075 |
1.90 |
56.3 |
12 x 12 |
0.041 |
1.0 |
0.042 |
1.06 |
25.4 |
12 x 12 |
0.035 |
0.9 |
0.048 |
1.22 |
33.2 |
12 x 12 |
0.032 |
0.8 |
0.051 |
1.29 |
37.5 |
12 x 12 |
0.028 |
0.7 |
0.055 |
1.39 |
43.6 |
12 x 12 |
0.023 |
0.58 |
0.060 |
1.52 |
51.8 |
14 x 14 |
0.032 |
0.8 |
0.039 |
1.52 |
29.8 |
14 x 14 |
0.025 |
0.63 |
0.046 |
0.99 |
41.5 |
14 x 14 |
0.023 |
0.58 |
0.048 |
1.22 |
45.2 |
14 x 14 |
0.020 |
0.5 |
0.051 |
1.30 |
51.0 |
16 x 16 |
0.028 |
0.7 |
0.035 |
0.89 |
30.5 |
16 x 16 |
0.023 |
0.58 |
0.040 |
1.01 |
39.9 |
16 x 16 |
0.018 |
0.45 |
0.045 |
1.14 |
50.7 |
18 x 18 |
0.020 |
0.5 |
0.036 |
0.91 |
41.1 |
20 x 20 |
0.016 |
0.40 |
0.034 |
0.86 |
46.2 |
24 x 24 |
0.014 |
0.35 |
0.028 |
0.71 |
44.2 |
28 x 28 |
0.010 |
0.25 |
0.026 |
0.66 |
51.8 |
30 x 30 |
0.013 |
0.33 |
0.020 |
0.50 |
37.1 |
30 x 30 |
0.012 |
0.30 |
0.021 |
0.53 |
40.8 |
35 x 35 |
0.012 |
0.30 |
0.017' |
0.43 |
33.8 |
35 x 35 |
0.010 |
0.25 |
0.019 |
0.48 |
42.4 |
40 x 40 |
0.014 |
0.35 |
0.011 |
0.28 |
19.3 |
40 x 40 |
0.012 |
0.30 |
0.013 |
0.33 |
27.4 |
40 x 40 |
0.010 |
0.25 |
0.015 |
0.38 |
36.0 |
40 x 40 |
0.0095 |
0.24 |
0.016 |
0.40 |
38.4 |
50 x 50 |
0.009 |
0.23 |
0.011 |
0.28 |
30.3 |
