Alibaba wholesale price Outdoor P10 yellow Color LED module P10 outdoor Amber Color LED module, 32X16 P10 Yellow ,Red,White
LED Modules from Glareled
Specifications
| P10 Green color Outdoor LED Module | |
| Technical parameter | |
| Module size | 320*160mm |
| Pixel pitch | 10mm |
| Pixel density | 10,000dots/m2 |
| Pixel configuration | 1G |
| Pixel resolution | 32*16 (W*H) |
| Total weight | 45kg/sqm |
| Best viewing angle | 8-150m |
| Temperature | Storage: -35degree~+85degree |
| Working: -20degree~+80degree | |
| Brightness of white balance | 3500cd/sqm adjustable |
| Operating ambient humidity | 10%--95% |
| MTBF | ≥10,000hours |
| Life span | ≥100,000hours |
| Flatness | Tolerance of interpixel ≤0.3mm |
| Tolerance of modules clearance≤0.6mm | |
| Power switch | Automatic switch |
| Horizontal viewing angle | 120degree |
| Vertical viewing angle | 110degree |
| Control method | Synchronization or asynchronization |
| Warranty time | 1years |
Specifications
semioutdoor led display can be produced in single red, single amber, white, blue, green colors.
and can customize your own size
Semi-outdoor led P10 modules single color hot sale!!!
Features:
1) Application: semioutdoor outdoor LED Panel
2) Pitch: 10mm
3) Module dimensions (W x H): 320mm x 160mm
4) LED composing: 1R per pixel
5) Density of pixel: 32 x 16 pixels per module; 10,000 dots/m2
6) Viewing angle (H/V): 110/55 degrees
7) Brightness: >10,000cd/m2
8) Driving method: 1/4 scan
9)Outdoor waterproof applicable and rigid package
10) Clear visibility high luminosity
11) Good reliability and low power consumption.
12)Customized requirements can be meet.
Application:
1.Public square Led display for commercial advertising
2.Stadium perimeter led display screen for live show
3.Mobile trailer led display screen for mobile media
ping mall led display for Promotional information
panies or shops LED display screen for logo showing
6.bank & stock exchange LED display screen for rates showing
7.air port & train & bus station LED display screen for the news or advertisement
ecommunication LED display screen system for information showing and instructinon
tal led display for culture, sports and social events
Glareled Showroom
CE and RoHS certification
Wooden box packing
