Specifications
1-Direct factory,
2-low price, high quality,
3-good after-sales service,
4-simple operation/Programmable
5-OEM/ODM Accep
P10 single/dual color 10mm indoor and outdoor/ monochrome and dual LED moving message display
P10 LED billboard moving screen sign Display size :(Width)640*(Height)160mm
Single color :red /yellow/amber/green/blue/white...
Working voltage:110V/220VAC or 12~36VDC
Signal communication :RS232 serial / network port / USB port(memory)
Message capacity:more than 120 different messages can be stored and displayed
Other information :
1)Offer CD(have software inside) and video manual for free;
2)Safety package :plywood box;
3)Offer good after service on operatetion of led sign ;
4)Warranty :2 years;
5)Short lead time :1~5 days;
6)Gross weight:6KG
| LED | 2R | Brightness | ≥ 6000cd/m2 | |
| Pitch | 16mm | Module size | 256x128mm | |
| Module pixels | 16x8pixels | Emitting color | R /Y/B /G /W /P | |
| Refresh rate | ≥ 360HZ | Control mode | Asynchronous(232, 485, GPRS)or by internet | |
| Frame | 60 frame/S | Communication distance | ≤ 150m net cable; ≤ 1000m optical fiber | |
| Drive mode | 1 /4 scan | Software interface | Windows2000/xp | |
| Watt | 200w/M2 | Display information | Text, news, advertising, flash, animation | |
| Working voltage | 110V /220V, 50/60HZ | Viewing angle | Horizontal: 120° , vertical: 60° | |
| Working temperature | -20degree---+60degree | Storage temperature | -40degree---+80degree | |
| Working humidity | 10%-95% | IP rate | IP33 | |
| Service Life | ≥ 100.000H | Defect rate | ≤ 0.001 | |
Those Sign can be use In :
1-,Hospital, Hotel,Airport,Train Station,
2- terminals, ferry harbours, car mounted signs, chain stores, square message boards, factories, banks, real estates, stock exchanges, post office, traffic control, ect
|
P10 Outdoor & Semi-outdoor LED sign Specification Technical Specification | |
Pixel Pitch |
10mm |
Density of Pixel |
10000dots/M2 |
Pixel configuration |
Red/Amber/Green/Blue/White/Dual color/Tri-color/ full color |
Size of Single Board |
320mm*160mm |
Best Viewing Distance |
≥10M |
Horizontal Viewing Angle |
120° |
Maximum Power Consumption |
≤750W/M2 |
Brightness |
≥ 3000cd/M2 |
Gray Scale |
14 bits per color |
Color Temperature |
6500k |
Control Method |
Asychronization/ sychronization |
Driving method |
1/4 scanning |
Frame Frequency |
60Hz |
Refresh frequency |
≥480Hz |
Working Voltage |
AC220V/110±10% |
IP grade |
IP65 |
Working temperature |
10 degree centigrade +70 degree centigrade |
Brightness adjustment |
256 grade manual, 8 grade automatic |
Software |
LED play software |
MTBF |
More than 10000 hours |
Life Span |
100,000 hours |
Optional
NO |
Pitch |
Pitch Pixel |
dot/sqm |
model |
View distance |
1 |
F3 |
4 |
62500 |
Indoor monochrome/ dual /full |
2-50 |
2 |
F3.75 |
4.75 |
44321 |
Indoor monochrome/ dual /full |
3-50 |
3 |
F5 |
7.62 |
17222 |
Indoor monochrome/ dual /full |
5-50 |
4 |
P6 |
6 |
27777 |
Semi Indoor monochrome/ dual /full |
6-50 |
5 |
P7.62 |
7.62 |
17222 |
Semi Indoor monochrome/ dual /full /full ko |
8-50 |
6 |
P10 |
10 |
10000 |
Both indoor and outdoor/ monochrome and dual /full |
10-60 |
7 |
P12 |
12 |
6944 |
Both indoor and outdoor/ monochrome and dual /full |
12-70 |
8 |
P14 |
14 |
5102 |
Both indoor and outdoor/ monochrome and dual /full |
14-80 |
9 |
P16 |
16 |
3906 |
Both indoor and outdoor/ monochrome and dual /full |
16-120 |
10 |
P18 |
18 |
3086 |
Both indoor and outdoor/ monochrome and dual /full |
18-140 |
11 |
P20 |
20 |
2500 |
Both indoor and outdoor/ monochrome and dual /full |
20-160 |
12 |
P25 |
25 |
1600 |
Both indoor and outdoor/ monochrome and dual /full |
25-200 |
13 |
P31.25 |
31.25 |
1024 |
Both indoor and outdoor/ monochrome and dual /full |
30-300 |
LED moving sign Application:
bank exchange rate information board,train station information board,shop window display,traffic information board,walk street information ,bus led sign ,in a word,any place need banner display .
Packaging includes
