Gsm 950 Mobile Phone Signal Boosting Gsm Signal

Name: Gsm 950 Mobile Phone Signal Boosting Gsm Signal
Brand: SKYLINE
SKU: 131624969

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SKYLINE

Model Number:

ST-GSM950

Skyline (Shenzhen) Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SKYLINE

Model Number ST-GSM950

Specifications

the mobile boosting gsm signal
can cover 300Sqm
approved by CE&ROHS
Signal amplifier signal repeater booster

gsm 950 mobile phone signal repeater boosting gsm signal amplifier

The Technical features:

*Receiving and sending separation , low require for Ant isolation ,making it convenient for installation.
    *Mini design with metal cavity filter technology inside.
    *ALC technology used to provide auto amplitude fixing.
    *Modules structures ,making it convenient for installation , debugging and maintenanceInstantly boost your cell phone signals!
Dual band GSM (900MHz/1800MHz) for worldwide use
Up to 800 square meter working range
Comes ready to go - no need for anything extra!
Powerful solution at an affordable price

Installation Approaches:

Fix up outdoor antenna reception on housetop and point to signal tower
Connect outdoor antenna to ''outdoor'' port in repeater machine through cable
Connect indoor antenna to ''indoor'' port in repeater machine through cable also
Plug power adaptor into AC power socket and finish installation

Where the repeater is using:

The Basic Parameter:

Working system	GSM900
Frequency range	Up link,890~915MHz Downlink,935~960MHz
Gain	Up link≥57dB Downlink60dB
Output up	Up link,17dBm Downlink,20Bm
Pass band ripple	≤1.8DB
I/O impedence	50Ω/N connector
Noise figure	≤6dB
Transmission delay	≤0.5μs
Ambient temperature	-15°C~55°C
Power supply	AC/220V±10% 45~55Hz DC,12V
Size	19814839m
Reliability	To the GB6993-86 standard
Electromagnetic compatibility	To the ETS300 694-4 standard
Function	a) Power supply LED denote b) Export power ELD denote
Coverage area	300Sqm

Package Included

	Europe Plug Adapter (2 Pin Round Pin): Europe countries, Africa, Middle East
	USA Plug Adapter (2 Pin Flat Pin): United States, South America, Caribbean, Canada, Japan, Korea, Philippines, Thailand and Taiwan
