steel shearing machine, guillotine shearing machine, Hydraulic Guillotine Shearing Machine
1. CE standard;
2. SIEMENS electrics.
3. linear guideway and ball screws
4.Optional NC/CNC
1) The machine employs hydraulically-driven swing beam, the steel plate welded structure,
and accumulator -based pullback cylinder with steady and reliable operation.
2) Indicator-based adjustment of gap of blade is convenient and fast. 3) The machine is equipped with lighting alignment device, and uses stepless control
for the stroke of up tool carrier.
4) The machine uses protection fence for safe operation. 5) Digital display device for size of back gauge and shearing times available.
| TECHNICAL FEATURES | ||
| 1 | Type | cnc Guillotine shearing machine |
| 2 | Cutting length | 2500mm |
| 3 | Cutting thickness | 8mm(mild steel at 450MPa) |
| 4 | Shear angle | 0.5-2 degree adjusted |
| 5 | Number of stroke per minute | 17 |
| 6 | Throat depth | 100mm |
| 7 | Stroke back gauge | 750mm |
| 8 | Main motor | 11kw |
| 9 | Main Electric elements in Cabinet | Schneider |
| 10 | Counter on back gauge | Delem DAC360, made in Holland |
| 11 | control axis | X + 3 |
| 12 | control details | backgauge,stroke, blades clearance or pressure |
| 13 | G.W. | 6000KGS |
| 14 | before packing size(mm) | 3200 x 1900 x 2200mm |
1. Warranty: 14 months after delivery the goods.
2. Payment: 30% down payment and 70% paid after receiving the copy of the documents.
3. Delivery: 30 days after receiving 30% down payment.
4. Loading: Plastic cover coat, through containers
5. Technique support and service: support twice operating training, first one is at my factory during the processing time, second one at the buyer’s factory during the re-installation/testing period. We will send our engineers go to buyer’s factory help to re-install this machine if customer required, and the customer need to pay for heir flight tickets(go and back), room and board, local travel cost.
