     Our BGA Rework Station/ BGA reballing station are widely used to replace and repair the BGA chip in laptop, mobile phone, xbox360,ps3,etc. The main user is repairing shops and factory to provide the after-sales service and rework.

      Repair steps:
1) Separate the BGA chip from mother board –we called desoldering
2) Clean Pad
3) Reballing or replace a new BGA chip directly
4) Alignment/Positioning – Depend on experience ,silk frame ,optical camera
5) replace a new BGA chip - we called Soldering

Product Application

 BGA rework station could be used in :

     Laptop / Notebook/ Computer motherboard repair.

     Playstation / XBOX 360 and other game console repair.

     Iphone 4/ 4s / 5 / 5s motherboard repair.

     TV / Video / ipad mainboard repai.

     SMD/ SMT / IC BGA rework

Main Features

  1.The upper and lower hot air heating,which can heat up at the same time from the top of the component to the bottom of the PCB;bottom IR heating,temperature precision control within ±1℃.8 segment temperature control independently.     motherboard repair tools


   2. Hot air district heating for BGA and PCB at the same time,and large area IR heater preheating up for the bottom of PCB to avoid completely PCB deformation during reworking,the upper or lower temperature zones could be used alone and combine freely the energy of up and lower heating element.

  3. Adopted high precision K-type thermocouple close-loop control and PID parameter self-setting system; bga welding machine

   4. Temperature curves can be displayed with instant curve analysis function and multi-group user data can be saved;temperature can be tested precisely through external measurement interface,curves can be analysed,set and correct on the touch screen at any time.

   5. Using high definition and adjustable CCD color optical alignment system,beam split,amplification,lessening,fine adjustment and auto focus with the function that automatic color aberration resolution and brightness adjustment,adjustable image contrast; equipped with 15 ” high definition LCD monitor.

   6.Adopting the HD touch human-machine interface;upper heating head and mounting head designed 2 in 1;providing many kinds of titanium alloy BGA tuyere can be rotated in 360 degree for easy installation and replacement.

   7. X,Y and R angle adopted micrometer fine-tuning,accuracy locating,precision can reach ±0.01mm.

   8. With the alarm function, after the BGA welding the machine can alarm by itself.In the case of temperature abuse, the circuit can power off automatically with the double over-temperature protection.Temperature parameter having password protection to prevent any modification.

Independent 2 heating zones temperature control system

Up-heater power: 1200W

Down-heater power: 1200W

Using high definition + CCD color optical alignment system+ high definition LCD monitor

Multi-functional and humanized operation system

HD touch human-machine interface +8 segments temperature controlling at the same time.

 Display 4 temperature curves and instant curve analysis function

Superior safety protection function

With passwork protection to prevent any modication.

Double over-temperature protection.
