PGL-B Series Spray Drying Granulating Machine

PGL-B Series Spray Drying Granulating Machine thumbnail-1
PGL-B Series Spray Drying Granulating Machine photo-1
US$ 230,000 - 890,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Yibu
Model Number:
PGL-B
Contact Supplier Request Quote Chat Now
Changzhou Yibu Drying Equipment Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name Yibu
Model Number PGL-B
Application Tablet
Type Granulator
After-sales Service Provided Engineers available to service machinery overseas

Application:

1.Pharmaceutical industry: tablet, capsule granule, granule of Chinese medicine with on or low sugar

2.Foodstuff; cocoa, coffee, milk powder, juice of granule, flavoring and so on.

3.Other industries: pesticides, feed, chemical fertilizer, pigment, dyestuff and so on.

Features:

1.Integrate spraying, drying fluid granulating in one body to realize granulating from liquid in one step.

2.Using the process of spraying, it is particularly suitable for micro auxiliary raw materials and heat sensitive raw materials. Its efficiency is 1-2 times that FL boiling granulating machine.

3.The final moisture of some products can reach 0.1%. It is equipped with powder returning device. The rate of granule forming is more than 85% with 0.2-2mm of diameter.

4.The improved inner roller multi-flow atomizer can treat the liquid extract with 1.3g/cm3 of gravity.

Technical parameters:

Item unit spec PGL-3B PGL-5B PGL-10B PGL-20B PGL-30B PGL-80B PGL-120B
liquid extract min kg/h 2 4 5 10 20 40 55
max kg/h 4 6 15 30 40 80 120
fluidization capacity min kg/batch 2 6 10 30 60 100 150
max kg/batch 6 15 30 80 160 250 450
specific gravity of the liquid kg/L ≤1.30
volume of material vessel L 26 50 220 420 620 980 1600
diameter if vessel mm 400 550 770 1000 1200 1400 1600
power of suction fan kw 4.0 5.5 7.5 15 22 30 45
power of auxiliary fan kw 0.35 0.75 0.75 1.20 2.20 2.20 4
steam consumption kg/h 40 70 99 210 300 366 465
pressure Mpa 0.1-0.4
power of electric heater kw 9 15 21 25.5 51.5 60 75
compressed air consumption m3/min 0.9 0.9 0.9 0.9 1.1 1.3 1.8
pressure Mpa 0.1-0.4
operating temperature °C automatically regulated from indoor temperature to 130°C
water content of product % ≤0.5% (depends on the material)
rate of product collection % ≥99%
noise level of machine dB ≤75
weight kg 500 800 1200 1500 2000 2500 3000
dim. of main machine Φ mm 400 550 770 1000 1200 1400 1600
H1 mm 940 1050 1070 1180 1620 1620 1690
H2 mm 2100 2400 2680 3150 3630 4120 4740
H3 mm 2450 2750 3020 3700 4100 4770 5150
B mm 740 890 1110 1420 1600 1820 2100
