FG Series Vertical Fluidizing Dryer

FG Series Vertical Fluidizing Dryer photo-1
US$ 230,000 - 890,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
yibu
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name yibu
Model Number FG
Usage Pharmaceutical
Voltage according to customer needs
Power(W) 1.5kw
Weight oen ton
Dimension(L*W*H) 1210X1260X2030MM
Certification CE:UL:FAD:ISO14001:9001
Warranty one years
After-sales Service Provided Engineers available to service machinery overseas
FG Vertical Fluidizing Dryer (Fluid Bed Dryer)


The machine is main used for drying powder or granules from pharmaceutical, foodstuff, chemical and so on industries.

Fluid bed to achieve fast heat transmission of medium.

Seal negative pressure operation, there is no dust.

Because of using anti-static material as filter, it is safe in operation;

The equipment has no dead corner so it is easy to clean fully and there is no cross pollution;

It is in conformity with the requirements of GMP.



Zhenzhou Biota Chemical Factory

Shengyang Hongmei Group

Guangdong Yiduoli Biota Technology CO., Ltd.

Guangdong Shunde Shunfeng Pharmceutical Company

Shanghai Baolong Pharmceutical CO., Ltd.

Rhodia(Wuxi) Pharmceutical CO., Ltd.

Jiangyin Huitong Chemical CO., Ltd.

Hainan Haifu Pharmceutical CO., Ltd.

Export Iran







Spec 3 5 30 60 120 200 300 500 1000
item unit
container raw material dim mm 300 400 700 1000 1200 1400 1600 1800 2200
volume L 12 22 100 220 420 670 1000 1500 2500
production capacity min Kg/batch 1.5 4 15 30 80 100 150 250 500
Max Kg/batch 4 6 36 72 140 240 360 600 1100
consume of steam Kg/batch 12 23 70 140 211 282 366 465 800
amount of compressed air m3/min 0.3 0.3 0.3 0.6 0.6 0.9 0.9 0.9 1.5
power of fan kw 2.2 4 5.5 11 18.5 22 30 45 75
temperature °C Adjustable from ambient to 120
collection rate % >99
time of operation min 15-30 (depends on material)
content of final product % ~0.2 (depends on material)
noise db ≤75
height of main machine mm 2100 2300 2500 3000 3300 3800 4000 4800 6200
